TIP33CG onsemi Bipolar Transistors - BJT 10A 100V 80W NPN

Product Details

Product Description

Product Description
Factory
Mfr. #:
TIP33CG
Manufacturer: onsemi
Product Category: Bipolar Transistors - BJT
RoHS: Details
Mounting Style: Through Hole
Package / Case: TO-247-3
Transistor Polarity: NPN
Configuration: Single
Collector- Emitter Voltage VCEO Max: 100 V
Collector- Base Voltage VCBO: 100 V
Emitter- Base Voltage VEBO: 5 V
Collector-Emitter Saturation Voltage: 1 V
Maximum DC Collector Current: 10 A
Pd - Power Dissipation: 80 W
Gain Bandwidth Product fT: 3 MHz
Minimum Operating Temperature: - 65 C
Maximum Operating Temperature: + 150 C
Series: TIP33C
Packaging: Tube
Brand: onsemi
Continuous Collector Current: 10 A
DC Collector/Base Gain hfe Min: 40
Height: 16.2 - 4 mm
Length: 15.2 mm
Product Type: BJTs - Bipolar Transistors
factory pack quantiy: 30
Subcategory: Transistors
Technology: Si
Width: 4.9 mm
Unit Weight: 0.229281 oz

---
