TECHNICAL PARAMETERS
Model
| ZB-20
| ZB-40
| ZB-80
| ZB-125
| ZB-200
|
Processing capacity (kg/per time)
| 10-15 | 20-30 | 40-50 | 70-80 | 100-140 |
Pot Volume(L)
| 20 | 40 | 80 | 125 | 200 |
Power(KW)
| 2.55 | 6.25 | 23 | 27 | 63 |
File quantity
| 3 | 3 | 6 | 6 | 6 |
Speed of cut pot (r/min)
| 16 | 12 | 8/12 | 8/12 | 8/12/16 |
File speed(r/min )
| 1650/3300
| 1800/3600
| 126/1800*3600
| 126/1800*3600
| 200/1900*3800
|
Dimension(r/min)
| 770*650*980 | 1245*810*1094 | 2300*1020*1195 | 2400*1420*1300 | 2580*2400*1960 |
Weight(KG)
| 215 | 480 | 1100 | 1300 | 3800 |
Power supply
| 380V | 380V | 380V | 380V | 380V |
FEATURES
1. The high-grade 9Cr15 stainless steel file produced by domestic famous manufacturers; also available with imported tools;
2. The pot is made by the professional founder of the first quality in China;
3. Tool speed, pot speed, the gap between the file and the crucible, the design of the file material and the hardness of the knife are reasonable. The gap between ZB-20.ZB-40 type file and pot is ≤1.5mm. The gap between ZB-80, ZB-125, ZB-200 type file and pot is ≤ 2mm;
4. The whole machine is made of 304 stainless steel, with fine workmanship, beautiful appearance, rigorous structure, simple operation and reliable performance.
5. Variable frequency acceleration, frequency conversion technology, large range of tool speed adjustment, high efficiency and energy saving function
