Product Description
Product Description
AIR DUST COLLECTOR FILTER CARTRIDGE
Product Details
| Brand | DONGJIE |
| Efficiency | 99.99% |
| Filter Cartridge Height | 16-52 inch |
| Flow Rate | 600-1000 m³/h |
| Porosity | 0.5μm |
| Pleat Width | 25-55mm |
Available with us is a wide array of Dust Collection Filter. These products are manufactured at par with the industrial as well as international standards of quality. Our products are available at the most affordable prices and can also be customized in terms of various designs as per the specific requirements of the valuable patrons.
Features:
·Durable and rigid material, washable
·Excellent resistance against electric conductance, oil and water
·Fine finish
Other Details:
·“DONGJIE” offers pleated dust collection filter Cartridges for gas handling – dust collection for effective solid-gas separation
·Pleated dust collection cartridges are available with flanged(Collar) type, double snap band type or Aluminum 3 – lock flange type
·Pleated three lock flanged type cartridges can be installed using tie rods in the cellar of outside of the filter cartridge
·“DONGJIE” recommends proper pleat height nos. of pleats based on pleat to pleat distance to avoid any Dead zone for Optimum utilization of filter cartridge
·For better efficiency of filtration and solid removal, “DONGJIE” recommends Aluminum coated filter media
·For reduced recurring expenses "DONGJIE" offers filter cartridges with removable core
Types of Dust Collecor Filter Cartridge
| Advantages
• High Pleat Separator • High Filtration Efficiency
Technology • 100% spun bond polyester
• Low Pressure drop • Pour in place one piece gasket
• Extended Filter Life • Broad design portfolio
|
Application: Air Pollution Control filter cartridge to collect dust, fumes and/or oil mist in many different industrial applications and processes
|
Type: Pleated Cylinder
|
Gasket: Rubber
|
Separator: Hot Melt Separator Technology
|
Sealant: Polyurethane
|
Temperature max: 80℃
|
Mounting/Frames: Perforated inner Core GV (optional Stainless steel)
|
Filter Class: M
|
Options: PA6 flange, 4-lug design
|
Dongjie filters are available as a retrofit upgrade your dust collector cartridges in the most popular shapes and sizes. Dongjie’s innovative pleating technology offers many valuable benefits in the operation of your dust collector.
• Lower pressure drop through open pleat spacing improves cleaning efficiency, which will reduce energy costs through less compressed air consumption during cleaning in many applications.
• More media available for filtration and therefore improved performance and longer life time.
• The separation beads, NOT the media beads, contact the inner cage, protecting the media from frictional damage.
• Dongjie media consists of 100% spun bond polyester in a pleated design that combines the high efficiency of cellulosic and the versatility of polyfelt - resulting in a premium filter with excellent performances.
• Ideally suited to tough applications including heavy dust loading conditions, high levels of fine particulate, and/or hygroscopic dust properties which limits the performance of cellulosic type filters.
| Model Name | Length(mm) | Media Area(m2) |
| DJ-ADF-300-01 | 300 | 1.1 |
| DJ-ADF-300-02 | 300 | 1.1 |
| DJ-ADF-300-03 | 300 | 1.5 |
| DJ-ADF-600-01 | 600 | 2.1 |
| DJ-ADF-600-02 | 600 | 2.2 |
| DJ-ADF-600-03 | 600 | 3.1 |
| DJ-ADF-1000-01 | 1000 | 3.5 |
| DJ-ADF-1000-02 | 1000 | 3.6 |
| DJ-ADF-1000-03 | 1000 | 5.1 |
| DJ-ADF-1200-01 | 1200 | 4.2 |
| DJ-ADF-1200-02 | 1200 | 4.32 |
| DJ-ADF-1200-03 | 1200 | 6.12 |
| Advantages
• High Pleat Separator • High Filtration Efficiency
Technology • 100% spun bond polyester
• Low Pressure drop • Pour in place one piece gasket
• Extended Filter Life • Broad design portfolio
|
| Application: Air Pollution Control filter cartridge to collect dust, fumes and/or oil mist in many different industrial applications and processes |
| Type: Pleated Cylinder |
| Gasket: Rubber |
| Separator: Hot Melt Separator Technology |
| Sealant: Polyurethane |
| Temperature max: 80℃ |
| Mounting/Frames: Perforated inner Core GV (optional Stainless steel) |
| Filter Class: M |
| Options: PA6 flange, 4-lug design |
| Modle Name | Length(mm) | Media Area(m2) |
| DJ-ADF-300-04 | 300 | 5 |
| DJ-ADF-300-05 | 300 | 10 |
| DJ-ADF-600-04 | 600 | 5 |
| DJ-ADF-600-05 | 600 | 10 |
| DJ-ADF-1000-04 | 1000 | 17 |
| DJ-ADF-1200-04 | 1200 | 20 |
| Advantages
• High Pleat Separator • High Filtration Efficiency
Technology • 100% spun bond polyester
• Low Pressure drop • Pour in place one piece gasket
• Extended Filter Life • Broad design portfolio
|
| Application: Air Pollution Control filter cartridge to collect dust, fumes and/or oil mist in many different industrial applications and processes |
| Type: Pleated Cylinder |
| Gasket: Rubber |
| Separator: Hot Melt Separator Technology |
| Sealant: Polyurethane |
| Temperature max: 80℃ |
| Mounting/Frames: Perforated inner Core GV (optional Stainless steel) |
| Filter Class: M |
| Options: PA6 flange, 4-lug design |
| Modle Name | Length(mm) | Media Area(m2) |
| DJ-ADF-600-06 | 600 | 10 |
| DJ-ADF-600-07 | 600 | 11 |
| DJ-ADF-660-06 | 660 | 10 |
| DJ-ADF-660-07 | 660 | 11 |
| DJ-ADF-660-08 | 660 | 17 |
| DJ-ADF-750-01 | 750 | 12.5 |
| DJ-ADF-1000-06 | 1000 | 11 |
| DJ-ADF-1000-07 | 1000 | 17 |
| DJ-ADF-1200-06 | 1200 | 17 |
| DJ-ADF-1200-07 | 1200 | 20 |
Product Images
Product Process
Packing & Delivery
Why Choose Us
1. Professional
Over 20 years' experience in filter filfield and exporting more than 70 counries. Dongjie Wire Mesh is the real professional manufacturer.
2. Product Quality
The quality of product is the key of the survival of enterprise . Dongjie Wire Mesh is a ISO9001:2008 certificated manufacturer.
3. Reasonable Price
We'll exactly control each producing process to reduce cost for our customers. After clients receiving the quotation, we 'll show you the rational priceand the difference between our products and other suppliers' products.
4. Delivery Time
We'll make a produciton plan before producinig, and the sales will regularly inform the production schedule and process to the customer.
5. Communication
English is the basic language and other language also can be understood. All customer's e-mail will replied within 2 hours at working hours and must be replied within 12 hours at non-working hours.
6. Customized
Personalized, professional service: We can provide different programs according to customer's requirement, thus make customers choose the best and appropriste one.
Our Certificate
FAQ
1. How to make an inquiry of AIR DUST COLLECTOR FILTER CARTRIDGE?
You need to provide material, diameter, size and the quantity to ask an offer. You can also indicate if you have any special requirement .
2. Could you provide free sample?
Yes, we can provide free sample together with our catalogue. But the courier charge will on your side. We'll send back the courier charge if you make an order.
3. How is your Payment Term?
Generally, our payment term is T/T 30% in advance and the balance 70% against the copy of B/L. Other payment term we can also discuss.
