MBRB20100CTG onsemi Schottky Diodes & Rectifiers 20A 100

Product Details

Product Description

Product Description
Factory
MBRB20100CTG
Manufacturer: onsemi
Product Category: Schottky Diodes & Rectifiers
RoHS: Details
Product: Schottky Diodes
Mounting Style: SMD/SMT
Package / Case: D2PAK-2 (TO-263-2)
Configuration: Dual Anode Common Cathode
Technology: Si
If - Forward Current: 20 A
Vrrm - Repetitive Reverse Voltage: 100 V
Vf - Forward Voltage: 950 mV
Ifsm - Forward Surge Current: 150 A
Ir - Reverse Current: 100 uA
Minimum Operating Temperature: - 65 C
Maximum Operating Temperature: + 175 C
Series: MBRB20100CT
Packaging: Tube
Brand: onsemi
Height: 4.83 mm
Length: 10.29 mm
Product Type: Schottky Diodes & Rectifiers
factory pack quantiy: 50
Subcategory: Diodes & Rectifiers
Termination Style: SMD/SMT
Type: Schottky Diode
Width: 9.65 mm
Part # Aliases: MBRB20100CTT4G
Unit Weight: 0.070548 oz

---
