CW61160L Horizontal Heavy Duty Lathe

Product Description

CW61160L Horizontal Heavy Duty Lathe
Main features:
These lathes can perform to turn end-faces, cylindricl surfaces and internal holes of various parts as well as metric, inch, module and pitch threads.
The top slides can be operated individually by power for cutting short taper surface also, can be turned automatically through the compound movement combining longitudinal feed with the top slide feed, moreover, the machinery may be used for drilling, boring and trepanning.
They are characteristics of power, high spindle speed, high rigidity. The various ferrous and non-ferrous metals parts may be turned through the heavy cutting by carbon alloytools.
Main specification:

SPECIFICATION		Model
		CW61125L	CW61140L	CW61160L	CW61180L	CW61190L
CAPACITY	Max.swing diameter over bed	1250	1400	1600	1800	1900
	Max.swing diameter over crossslide	880	1030	1230	1400	1500
	Width of bed	1100mm
	Max.length of workpiece	1000 -8000mm
SPINDLE	Spindle nose	A15
	Sindle bore diameter	130mm
	Taper of spindle bore	Metric No.140#
	Range of spindle speed	3.15-315r/min 21kinds
FEEDS	Longitudinal feeds range	0.1-12mm/r 56 kinds
	Transversal feeds range	0.05-6mm/r 56kinds
	Metrec thread range	1-120mm 44kinds
	Inch thread range	3/8-28TPI 31kinds
	Module thread range	0.5-60mm 45kinds
	Pitch thread range	1-56TPI 25kinds
TAILSTOCK	Tailstock sleeve taper	Metric 80#
	Tailstock sleeve diameter	260mm
	Tailstock sleeve travel	200mm
MOTOR	Main motor power	30kW
	Rapid motor power	1.5kW
	Coolant pump power	0.125kW

---
