| US$80.00-2,000.00 | 10 Pieces (MOQ) |
| Product Name | Datashhet & Specifications | Describe | Unit |
| Item No. | YAYE-UPS-6KWA | ||
| Reverse Control Integrated Machine | 6KW Sine Wave 6210wh Ningde Era Ternary Lithium Battery | 6000W | W |
| Photovoltaic Panels | 450W*6pcs Mono Panels 36V High Efficiency Generator Board | 2700W | W |
| Photovoltaic Panel Bracket | 6pcs X 450W Solar Panel Brackets | 2700W | W |
| Lithium Battery | 51.2V with 120AH | 120 | AH |
| Stored Power ( KWH) | 6.21KWH | 6.21 | KWH |
| PV Panel Main Line | 2.5 Square 2 Groups 2 Plus 2 Minus | 15M | M |
| Item No. | YAYE-UPS-6KWB | Describe | Unit |
| Reverse Control Integrated Machine | 6KW Sine Wave 10240wh Ningde Era Ternary Lithium Battery | 6000W | W |
| Photovoltaic Panels | 450W*9pcs Mono Panels 36V High Efficiency Generator Board | 4050W | W |
| Photovoltaic Panel Bracket | 9pcs 450W Solar Panel Brackets | 4050W | W |
| Lithium Battery | 51.2V with 200AH | 200 | AH |
| Stored Power ( KWH) | 10.12KWH | 10.24 | KWH |
| PV Panel Main Line | 2.5 Square 2 Groups 2 Plus 2 Minus | 30M | M |
| Item No. | YAYE-UPS-6KWC | Describe | Unit |
| Reverse Control Integrated Machine | 6KW Sine Wave 13000wh Ningde Era Ternary Lithium Battery | 6000W | W |
| Photovoltaic Panels | 450W*12pcs Mono Panels 36V High Efficiency Generator Board | 5400W | W |
| Photovoltaic Panel Bracket | 12pcs X 450W Solar Panel Brackets | 5400W | W |
| Lithium Battery | 51.2V with 260AH | 260 | AH |
| Stored Power ( KWH) | 13KWH | 13 | KWH |
| PV Panel Main Line | 2.5 Square 2 Groups 2 Plus 2 Minus | 30M | M |
| Specifications | Photos | ||
| AC Input Voltage Range | AC185-265V50/60Hz | ||
| Temperature Protection | ≤80ºC | ||
| Overload Protection | ≤6600W | ||
| Output Voltage/Frequency | 220V/50Hz | ||
| Output Power | Rated 6000W | ||
| Output Waveform | Sine Wave | ||
| Built-in Charging Current | 20A | ||
| UPS Reaction Time | ≤5ms | ||
| 12VDC Output | 12V/24W( max) | ||
| USB DC Output | 5V/10W (max) | ||
| Random Accessories | Description * 1 | ||
| Host size L*W*H (MM) | 680*320*720MM | ||
| Host Weight (KG) | 82.5-120KGS | ||
| Carton Size L*W*H (CM) | 72*50*76cm | ||
| Carton Weight Included (KG) | 103-140KGS | ||
