| Negotiable | 1 Set (MOQ) |
| Model | SJ-A45 | SJ-A50 | SJ-A55 | SJ- A65 | |
| Suitable material | HDPE LDPE LLDPE | ||||
| Film width(mm) | 100-500 | 300-600 | 400-800 | 600-1200 | |
| Film thickness(mm) | HD | 0.009-0.05 | 0.009-0.15 | ||
| LD | 0.02-0.15 | 0.03-0.15 | |||
| Max.Extrusion output(kg/hr) | HD | 40 | 45 | 55 | 65 |
| LD | 45 | 50 | 60 | 70 | |
| Extruder | |||||
| Screw diameter(mm) | 45 | 50 | 55 | 65 | |
| Screw L/D length | 28:1/30:1 | ||||
| Screw material | SACM-645/38CRMOALA | ||||
| Cylinder material | SACM-645/38CRMOALA | ||||
| Cylinder cooling | 180x2 | 250x2 | 370x2 | 550x2 | |
| Driving motor (kw) | 7.5 | 11 | 15 | 22 | |
| Temperature control | 3 | 3 | 3 | 4 | |
| Average power-consume(kw) | 10 | 12 | 18 | 30 | |
| Type of die | |||||
| Die size | HD | 60/80 | 80/100 | 100/120 | 100/150 |
| LD | 100/120 | 120/150 | 180/200 | 220/ 250 | |
| Temperature control | 3 | ||||
| Air ring | 1 | ||||
| Air blower(kw) | 1.5 | 2.2 | 3 | 4 | |
| Center steady stick | 1 | ||||
| Take-up unit | |||||
| Roller width(mm) | 165×650 | 165×850 | 165×1100 | 165×1400 | |
| Height adjustable type | 800mm | ||||
| Take-up speed(m/min) | 10-100 | 10-100 | 10-80 | 10-80 | |
| Take-up motor(kw) | 0.75 | 1.1 | 1.1 | 1.5 | |
| Winding unit | |||||
| Type | Surface friction type | ||||
| Winding motor(N.m) | 10 | 10 | 10 | 16 | |
| Winding speed(m/min) | 10-100 | 10-100 | 10-80 | 10-80 | |
| Cover dimension(m) | 5.0×2.0×4.1 | 5.0×2.2×4.5 | 5.5×2.5×5.2 | 5.8×2.8×6.3 | |
