| US$1,200.00-2,500.00 | 1 Set (MOQ) |
| Screw Size | 1:28 | 1:33 | 1:38 | |||
| Speed (rpm) | Output (kg/h) | Speed (rpm) | Output (kg/h) | Speed (rpm) | Output (kg/h) | |
| Φ45 | ~70 | 50 | ~120 | 80-120 | ~150 | 120-180 |
| Φ60 | ~70 | 100 | ~120 | 180-250 | ~150 | 300-350 |
| Φ75 | ~70 | 160 | ~120 | 300-400 | ~150 | 400-500 |
| Φ90 | ~70 | 250 | ~120 | 400-500 | ~150 | 600-700 |
| Φ120 | ~70 | 350 | ~120 | 700-800 | ~150 | 800-1000 |
| Φ150 | ~70 | 500 | ~120 | 1000-1200 | ~150 | 1200-1500 |
| PARAMETERS | |
| Suitable Machines | Pipe, Profile, Sheet, Film, Tube.. |
| Application Field | Household, Agriculture, Industry, Building, Auto Parts, Electronic Parts.. |
| Applied Polymers | PE, PE, PA, PET, PVC, PC, ABS, PBT, PEEK, Teflon, HFFR.. |
| Screw Treatment | Nitrided, Bimetallic, PTA, HVOF, Tool Steel, HSS, PM Steel.. |
| Reinforced Additives | CaCo3, Talc.. |
| Hardness | 58-64HRC |
| Straightness | 0.02mm/m |
| Roughness | Ra0.2-0.4 |
| Max. Temperature | 600 Degree |
| Warranty Period | 1/2/5 Years |
