| Model | PTSS | 400 | 500 | 600 | 800 | 1000 | 1200 | 1500 |
| Motor power(kw) | 7.5 | 15 | 18.5 | 37 | 45 | 55 | 75 | |
| Rotation diameter(mm) | Φ170 | Φ220 | Φ220 | Φ400 | Φ400 | Φ400 | Φ400 | |
| Shredding width(mm) | 400 | 500 | 600 | 800 | 1000 | 1200 | 1500 | |
| Rotation speed(Rpm) | 80 | 80 | 80 | 80 | 80 | 80 | 80 | |
| Rotated blades number | 15 | 23 | 27 | 39 | 49 | 59 | 84 | |
| Fixed blades number | Upper fixed blades | 2 | 2 | 2 | 2 | 2 | 3 | 3 |
| Lower fixed blades | 2 | 2 | 2 | 2 | 2 | 3 | 3 | |
| Hydraulic power(kw) | 1.5 | 2.25 | 2.25 | 3.75 | 3.75 | 5.5 | 5.5 | |
| Ram(mm) | 350 | 500 | 500 | 815 | 815 | 815 | 815 | |
| Rotor blades size(mm) | 30*30 | 40*40 | 40*40 | 40*40 | 40*40 | 40*40 | 40*40 | |
| Screen amount | 1 | 1 | 1 | 1 | 2 | 2 | 2 | |
Dimension | L | 1400 | 1820 | 1820 | 2800 | 2800 | 2800 | 2800 |
| W | 990 | 1190 | 1310 | 1800 | 1980 | 2500 | 2750 | |
| H | 1600 | 1730 | 1730 | 2090 | 2090 | 2140 | 2140 | |
| A | 1010 | 1210 | 1210 | 1420 | 1420 | 1420 | 1420 | |
| B | 840 | 990 | 1090 | 1500 | 1700 | 1900 | 2100 | |
| C | 380 | 490 | 490 | 570 | 570 | 570 | 570 | |
| D | 260 | 270 | 270 | 530 | 530 | 530 | 530 | |
| E | 400 | 500 | 600 | 800 | 1000 | 1200 | 1500 | |
| Weight | 750 | 1500 | 1750 | 4150 | 4300 | 4900 | 7280 |
| Suzhou Polytec Machine Co LTD focuses on the R&D and manufacturing of complete set of waste plastic recycling and processing systems and has provided services to customers in more than 30 countries through high-quality customized solutions, professional real-time technology and after-sales service. POLYTEC is currently working on four directions: 1. Waste plastic cleaning and classification: waste plastic films, bags, barrels, bottles, etc. are broken and cleaned, and plastics of different materials are separated, which are directly used in downstream industries such as recycled plastic granulation; 2. Recycled granulation of waste plastics: recycled granulation after cleaning of factory materials and post-consumer plastics; 3. Development of key machinery for recycling and recycling: R&D and manufacturing of key models for different materials in different industries, and provide key equipment for various process routes; 4. Waste electronic waste treatment: Provide system-wide process design and development and reuse for the growing consumer electronic products. 5. Design and implementation of project engineering: Our company provides guidance on plant design layout in the early stage of the project, and the overall installation of on-site water and electricity |
| Technology: |
| With Austrian Technology & Made in China Complete machine range: waste plastic washing line and pelletizing line Use our own factories to manufacture waste plastic recycling machines With many patents |
| Team: |
| Our CEO with over 20 years' rich experience in international trade business Our staff have over 15 years' rich experience in machine R & D, manufacturing and testing field, assembling workers with over 5 years' rich experience in our industry |
| Certificates: |
| With CE certificate Can meet UL/ISO/ standards With more than 15 national patents. |
| Profession: |
| English, French are available Customized machines are welcomed Instructions and other files are equipped The machine supports the third-party inspection for quality assurance |
| Services: |
| Perfect pre-sales service and after-sales service Support machine testing by using customer's raw material After--sales machine testing service is available. |
| Sample projects: |
| We already provided machines for customers over 30 countries, such as America, Mexico and so on. Some projects can be visited for reference. |
| SERVICE SUPPORT |
| Sales service |
| Common problems with our plastic recycling machines |
| 1,How do I get a quick response from the product? |
| You can send email for our product details and we can also chat in quick tools such as WeChat, WhatsApp, Viber, LinkedIn, Facebook, etc. |
| 2,How soon can I get a quotation? |
| For most projects, we can quote you within 24 hours once we know the necessary information to recycle the raw material. |
| 3,Can I have a custom design? |
| We design and build each project according to the needs of our customers. Customization is based on requirements (e.g., 480V60Hz in the US, 440V/220V60Hz in Mexico, 380V60Hz in Saudi Arabia, 415V50Hz in Nigeria). |
| 4,Is there a minimum order requirement? |
| Due to the large daily production capacity and high freight cost, our minimum order quantity is 1 set, but we can help to choose several colors. It is recommended that you order 20 "GP or 40" HC to reduce unit price and shipping cost. |
| 5,What are your office hours? |
| You can contact us at 8 o 'clock. M. 5 PM to 5 PM +8 PM, Monday to Saturday, except Chinese national holidays. |
| 6,Do you have a price list? |
| We are a professional plastic recycling machine manufacturer. We have different models, even for the same material type of recyclers, it is recommended to ask for price/quotation according to actual needs (e.g. Ability or your rough budget). |
| 7,A: How do I know If I can trust your order? |
| We have been in business since 2003 and are committed to delivering 100% customer satisfaction. If the customer allows access, you can access them. |
