| US$18,500.00 | 1 Piece (MOQ) |
| Item | Name | Mm | |
| 1 | saw blade diameter | Φ80-400mm | Need special parts if diameter less than 140mm |
| 2 | Max Saw blade thickness | 6mm | |
| 3. | Saw blade hole | Φ22-25 , 4-32-40-50 | |
| 4 | Teeth type | BW, CW>Φ200 | |
| 5 | Degree | -10o-28o | |
| 6 | Teeth distance | Max 24mm | |
| 7 | Teeth quantity | 10-999 teeth | |
| 8 | Speed | 1-50 teeth/min | |
| 9 | grinding wheel motor power | 4 KW | |
| 10 | grinding wheel type | Cubic Boron Nitride) | |
| 11 | Grinding wheel size | Φ200 | |
| 12 | Grinding wheel feeding servo motor power | 0.75KW | |
| 13 | Motor power | 6 KW | |
| 14 | Machine size | 1500 X 1430 X 1690mm | |
| 15 | Machine weight | 1380 kgs | |
