Gasoline Brush Cutter Cg-430b

Product Description

Lawn Mower
Model: CG-430B
Type of handle: Double handle
Driving model: Automatism centrifugal Clutch
Type: 1-cylinder, 2-stroke, air-cooled
Rotating direct of blade: Counter-clockwise
Speed reducing ratio: 1.25
Blade: Rhombus 3teeth, 4teeth, 8teeth, 30teeth, 40teeth, 80teeth, nylon cotting head
Engine: 1E40F-5A
Displacement: 42.7CC
Max. Output power: 0.75/6500(kw/r/min)
Fuel oil: Gasoline and two-cycle oil: 25: 1
Carburetor: Pump oil type
Max. Ful consumption: <=610g/kw/h
Start system: Self-return hand-operated start
Oil tank capacity: 1.0L
Diameter of Aluminium pipe(mm)26
Working Form: SHOULDER
Noise: <=104dB(A)
N. W/G. W: 9.4kg/11.1kg
Engine case size: 330*300*250mm
Shaft case size: 1660mmx110mm x 110mm
Certificate: CE, ISO9000-14000

Model	CG-430B	CG-430B-1	CG-411B	CG-328B	T200
Engine	1E40F-5A	1E40F-5B	1E40F-6	1E36F	1E39F
Displacement(cc)	42.7	42.7	40.2	30.5	39
Standard power(kw/r/min)	1.25/7000	1.25/7000	1.45/7000	0.81/6500	1.5/7000
Form of carburetor	diamphragm	diamphragm	floattype	floattype	floattype
Mixed Fuel Ratio	25:1	25:1	25:1	25:1	25:1
Tank capacity(L)	1.2	1.2	0.85	1.0	1.0
Diameter of aluminum pipe(mm)	26	26	26	26	26
Working form	Shoulder	Shoulder	Shoulder	Shoulder	Shoulder
Weight(kg)	7.5	7.5	7.7	7.8	8.5
Engine Dimension(mm)	330*300*250	405*300*280	330*300*250	330*300*250	330*300*250
Working pole Dimension	1660*110*110	1660*110*110	1660*110*110	1660*110*110	1660*110*110

---
