High Performance Disc Ridger for Tractor Mounted for Farm Field Work

Product Description

Farm Implement Agricultural Machine Three Point Mounted Adjustable Disc Ridger For Tractor Product Description
3ZM adjustable ridger is mainly used for making ridge in the field after tillage.The main frame is made of rectangular tube welded together ,assembled with the angle adjustable disc ridging unit .The discs are made of qualified 65Mn steel plate with heat treatment .The machine is steady and durable ,convenient for transport and easy to adjust ,operate and maintenance.

Product Parameters

Model	Unit	3ZM-80	3ZM-120	3ZM-140	3ZM-160	3ZM-180	3ZM-260
Working Width	MM	800	1200	1400	1600	1800	2600
Ridger Width	MM	200-450	200-450	200-450	300-500	300-500	300-500
Ridger Height	MM	150-240	150-240	150-300	150-300	150-300	150-300
Matched Power	HP	20	25-30	30-40	50	50-70	70-90
Total Weight	KG	135	150	165	180	200	350
Linkage	Three-pointed Mounted

Detailed Photos
After Sales Service
12 months guarantee of the main parts, we will send the guarantee parts together with the machine in your next order or we can send them by air express if you need it urgently.

FAQ
1.Q: Full price list for these products.
A: If you need the price list for these products, please notify the product model so that I can quote you accordingly. Please understand we have a very wide product range, we don't usually offer full products price list. 2. Q: Business terms A: Shipment time: 25-40days after your payment. Shipment: By sea Loading port: Shanghai port, China Destination port: ...To be advised Payment: T/T Warranty: 1 year 3.Q:How can I order from you? A: Please send us your enquiry list; we will reply you within two working days. 4.Q:If the finger I look for are not in your catalogue, what should I do? A: We can develop it according to your drawing or sample. 5. Q: Why choose us for cooperation? A: Comparing with our competitors, we have much more advantages as follows: 1. More than 30years in manufacturing farming machine.
2. More Professional Sales staffs to guarantee the better service. 3. More agri machines for your choice. 4. More New products into your range to avoid price competition. 5. Larger quantity production and shipment. 6. Better quality to guarantee better Credit. 7. Faster delivery time: Only7days. 8. More stick quality checking before shipment. 9. More reasonable after-sales service terms.

---
