X5036 Good Price Manual 3 Axis Dro Vertical Milling Machine Tools for Sale

Product Description

This machine has the following features:
1.X5036A vertical milling machine body adopts advanced cast iron, the high precision, long life after the artificial aging treatment
2.X5036A vertical milling machine spindle rigidity, strong bearing capacity, the bed is a rectangular guide bed, good stability.
3.X5036A vertical milling machine X, Y to the control of the machine tool by box type, can achieve automatic feeding, Z to the use of motor automatic lift.
4.X5036A vertical milling machine X, Y, Z three direction of the guide rail hardening, precision grinding. Plastic slide
After the motion precision and life and taste
5.Equipped with manual lubrication device can be used to guide screw and guide rail.
6.X5036B vertical milling machine is a kind of common metal cutting tools. This tool spindle cone can be directly or through the attachment of cylindrical milling, installation, end milling cutters, Angle cutter knives, applicable to such processing various parts of the plane, cant, groove, holes etc, machinery manufacturing, mould, instrument and meter, automobile, motorcycle industries ideal processing equipment.
The main specification of the machine

SPECIFICATIONS	X5036A	X5036B
Spindle taper	7:24 ISO50	7:24 ISO50
Distance.spindle to tabie surface mm	80-440	70-450
Spindle center to column guideway surface distance mm	320	360
Spindle speed range r/min	60-1700(12)	60-1690 (12)
Mill Head rotation angle	±45°	±45°
Table size mm	1250×360	1500×360
Table travel (X/Y/Z) mm	600/320/360	1000/320/380
Table longitudinal/lateral Speed of mm/min	22-555(8)810()	15-370(8)540()
Table vertical speed motor movements mm/min	590	590
Table T-slot number/width/spacing mm	3/18/80	3/18/80
Main motor power kw	4	4
Table motor power feed motor w	750	750
Lift motor power down feed w	1100	1100
Cooling pump motor powe w	90	90
Cooling pump flow	25	25
Machine NW/GW (kg)	2200/2400	2230/2400
Overall size(mm)	1700×1680×1880	2220×1790×1980
