BL160G Ethernet Switch Din Rail Mount Ethernet Switch Wall Mounts Included

Product Description

Product Description
Industrial Ethernet switch BL160G supports 1 10/100/1000Base-TX uplink port and 4 10Base-T/100/1000Base-TX downlink port. Products comply with FCC, CE, ROHS standards. BL160G industrial switch has a working temperature of -40ºC ~ 75ºC, with superior robustness to adapt to a variety of harsh environments, can also be very convenient to be placed in a compact space control box. The installation characteristics of the guide rail, wide temperature operation, IP40 protection housing and LED indicator light make the BL160G industrial switch a plug and play industrial device, providing a reliable and convenient solution for users to network their Ethernet devices.
1,The use of high-quality photoelectric integration module to provide good optical and electrical characteristics;
2,Ensure reliable data transmission and long working life;
3,Support full-duplex or half-duplex mode, with automatic negotiation ability;
4,Network port supports automatic cross identification;
5,With store and forward mechanism, support a variety of protocols;
6,Meet industrial operation standards, the average trouble-free work in more than 300,000 hours;
7,Working power supply: DC 48-57V provides reverse connection protection;
8,Lightning surge impact protection (power supply) : 5000A(8/20μs) Product Parameters

BL160G specification introduction
Power	Power Input	DC12-52V(Dual Power Redundant Backup)
	Access terminal	Phoenix terminal
	Dual power redundancy	Support
	Built-in overcurrent 4.0A protection	Support
	Reverse connection protection	Support
LED Indicators	Power indicator	PWR
	Interface indicator	Electric port(Link)
RJ45 ports	RJ45 specification	5xRJ45,10/100/1000BaseT(X)automatic detection,MDI/MDI-X adaptive
	Standards	IEEE802.310BASE-TIEEE802.3i; 10Base-T;IEEE802.3u;100Base-TX/FX; IEEE802.3ab1000Base-T;IEEE802.3z1000Base-X;IEEE802.3x; IEEE802.3af; IEEE802.3at
Switch properties	Transmission mode	Store-and-forward
	Packet Buffer Memory	1.2Mbit
	Switching delay	<10μs
	MAC Address Table	2K
	Bandwidth	14G
	Power dissipation	<3W
Certification	MTBF	300,000 hours
	EMI	FCC Part 15 Subpart B Class A,EN 55022 Class A
	EMC	IEC(EN)61000-4-2(ESD):±6kV(contact),±8kV(air)
		IEC(EN)61000-4-3(RS):10V/m(80~1000MHz)
		IEC(EN)61000-4-4(EFT):Power Port : ±2kV CM//±1kV DM
		IEC(EN)61000-4-5(Surge):Power Port : ±2kV CM//±1kV DM
		IEC(EN)61000-4-6:3V(10kHz~150kHz),10V(150kHz~80MHz)
		IEC(EN)61000-4-16:30V cont. 300V,1s
		IEC(EN )61000-4-8
		Shock :IEC 60068-2-27
		Freefall :IEC 60068-2-32
		Vibration :IEC 60068-2-6
Working Environment	Working temperature	-40~75 ºC
	Storage temperature	-40~80 ºC
	Relative Humidity	5%~95%( no condensation)
Mechanical properties	Shell	Metal shell
	Dimensions	118 x 86x 33mm
	Protection type	IP40
	Weight	0.36Kg
	Installation method	DIN rail
	Heat dissipation mode	Natural cooling, no fan
Warranty	Warranty period	1 year
