Bee Wax Chemical Machinery for Granulating Machine

Product Description

Product Description The rotating belt condensation granulator, by the distributor, makes the fusing materials from the upstream process drop evenly on the steel belt moving a constant speed underneath. There is a water return device under the steel belt which can spray cooling water to cool and solidify the fusing material during the course the material is moving, achieving the aim of granulation.
According to the material properties and operating requirements, the distributing device can make half spherical, strip or slice products by different operation such as continuous dropping, continuous making strip or full width spillover.

Model	Strip width (mm)	Capacity (Kg/h)	Steel belt/distributOr (Transmission Power Kw)	Total length (m)
BSCF 600	600	100-400	1.5/2.2	18.2
BSCF 1000	1000	200-800	5.5/2.2	18.2
BSCF 1200	1200	300-1000	5.5/2.2	18.2
BSCF 1500	1500	500-1200	5.5/2.2	18.2
1. Capacity depends on the performance of specific materials. 2. Particle size shall be determined according to customers' needs

APPLICATION The rotating belt condensation granulator, is appropriated for material of melting point not more than 250ºC needing to coagulate and be granulation. For example: sulfur, paraffin, petroleum resin, C5 resin, C9 resin, C5c9 polymer resin, sulfide sodium, pitch, maleic anhydride, stearic acid products, hot melt adhesive, kinds of additive, rubber, plastic additive, antioxidant, light stabilizer 622/944 and so on.(Chart: granulation molding product samples)
Banghua International Granulation Engineering Co., Ltd is professional on the design, manufacture, installation and commissioning of hot air furnace, heat exchanger, and complete set of fluidized-bed spray granulation, evaporation, concentration and drying equipment. We can provide customers with professional systematic overall solution.
Main advantage
1.The granulation size and form can be chosen.
2.The distributor and the steel belt both adopt the frequency conversion stepless speed governing device for adjusting the control according to the production capacity and material parameters.
3.Avoid dust during discharging, and protect the particle shape.
4.Due to its smooth running and lower noise, the working conditions can be improved, thus the production efficiency can be improved.
5.The distributor and steel belt both adopt frequency control, so suitable speed can be chosen according to different of material properties to adjust and control.
Banghua has passed ISO9001 international quality system certification. We have perfect R&D system, quality management system and professional construction team. Banghua has successfully undertook hundreds of projects of equipment design, manufacture, installation and commissioning in both domestic and international market, including hot air furnace, complete set of drying equipment, continuous fluidized bed spray granulation, evaporation and concentration equipment.
Banghua people who is realistic and pragmatic, innovative and enterprising adheres to the business philosophy of "base on sincerity, win-win cooperation". We provide customers at home and abroad with advanced technology, first-class products and premium service. Banghua persists not only to create more value for customers, but also try our best to save energy, protect the environment and promote harmony between human beings and the environment.
Why Choose Us
Professional with 15-year experience; High quality and competitive price;
Customer oriented systematic overall solution;
Perfect after-sales service.
Any questions, please feel free to contact. Sally Wu

---
