Broadband Polarizing Cube Beamsplitters/Polarizing Cube Beamsplitter

Product Description

General Introduction: Raytek broadband polarization cube beam splitter provides efficient polarization for multiple or tunable sources. Each polarizer consists of a pair of right angle prisms which are carefully bonded together to minimize wavefront distortion..
Products Name: Broadband Polarizing Cube Beamsplitters
Alias: Broadband Polarizing Cube Beamsplitters, Polarizing Cube Beamsplitters, Broadband Cube Beamsplitters, Optical Cube Beamsplitters, Optical Beamsplitters, Polarizing Optical Cube Beamsplitters, etc
Bandpass Filters Substrates:
SF 2, NSSK grade

Optional I:	SF 2, NSSK grade from CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,ETC
Optional II:	Equivalent SF 2, NSSK grade Made in China, C-laser own brands

Main Applying:

Applying Fields I:	Interferometers; Autocorrelation; Cameras; Projectors and laser systems,etc.
Applying Fields II:	Other
*****

Main Characters:
1).Extinction ratio >500:1, 1000:1 average
2).Superior broadband performance
3).Low wavefront distortion
4).Constructed with a pair of right angle prisms
5).Broadband multilayer coating
Products Highlights:
1).Different grades materials for option.
2).High precision & high surface roughness;
3).Sizes can be customized as per the customers' request
4).Quick lead time and delivery time.
5).Matching super optics custom and processing capacity, including Moulding, CNC machining, Polishing, Particle beam processing, Magnetic flux conversion processing, Grinding, Coating, Lightweighting, Custom Shaping, Counterbores, Drilling & Coring, Edge & Bevel Polishing,3D Contouring, Bevels & Chamfers, Steps & Slots, Laser Cutting & Marking, Metrology & Inspection, Precision Pitch Polishing, Double-Sided Polishing, Optical Assembly, Measuring, etc.
6).Excellent post-sale quality warranty, with "3R"-return, replace & refund policy
Main Optical Tech Specification:

Tech Data	Description
Type	Cube Beamsplitters
Material	SF 2, NSSK grade
Coating Type	Broadband polarizing
Antireflection Coating	Multilayer broadband dielectric
Surface Quality	20-10 scratch-dig
Surface Flatness	≤λ/4 at 632.8 nm
Extinction Ratio	Tp/Ts >500:1, 1000:1 average
Wavefront Distortion	≤λ/4 at 632.8 nm over the clear aperture
Angle of Incidence	0°±5°
Damage Threshold	2000 W/cm2 CW, 1 J/cm2 with a 10 nsec pulse, typical
Orientation	To avoid damage, beam should enter prism marked with a dot
Reflection	Rs >99.5% average
Reflected Beam Deviation	90° ±5 arc min
Transmission	Tp >80%, >90% average
Transmitted Beam Deviation	≤5 arc min
Clear Aperture	>80% of central dimension
Operating Temperature Range	-50 to 90°C
Durability	MIL-C-675C, moderate abrasion million cycles

Popular Physical Size Specification:

Size	12.7*12.7*12.7mm 25.4*25.4*25.4mm 50.8*50.8*50.8mm Design & custom manufacturing as per demand.
Size Tolerance	±0.254 mm
Thickness	Design and custom as per demand
Thickness Tolerance	-
Wavelength Range	420-1600nm or design & custom manufacturing as per demand

Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Raytekoptics Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with "3R" policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.

---
