10g SFP+ Fiber Transceiver Bidi 10gbase-Bidi 1270nm/1330nm SMF, up to 10-80 Km, Compatible with Cisco SFP-10g-Bxd-I/SFP-10g-Bxu-I, Ubiquiti, Mikrotik, Netgear

Product Description

10Gbps BIDI XFP 80KM Transceiver / Module
Product Features
Hot-pluggable XFP footprint Supports 9.95Gb/s to 11.3Gb/s bit rates XFI Loopback Mode RoHS-6 Compliant (lead-free) 1270nm DFB laser and PIN receiver for LASX-T2733X-ER 1330nm DFB laser and PIN receiver for LASX-T3327X-ER Power dissipation<2W Case operating temperature 0 ºC~70ºC Up to 40km transmission on SMF 2-wire interface with integrated Digital Diagnostic monitoring EEPROM with Serial ID Functionality Compliant with XFP MSA with LC connector
Applications
10GBASE-BX 10.3125Gb/s Ethernet 10GBASE-BX 9.953Gb/s Ethernet SONET OC-192 &SDH STM I-64.1
Product Description
LASX-T2733(3327) X-ER is hot pluggable 3.3V Small-Form-Factor transceiver module. It designed expressly for high-speed communication applications that require rates up to 11.3Gb/s, it designed to be compliant with XFP MSA. The module data link up to 40km in 9/125um single mode fiber.
Absolute Maximum Ratings

Parameter	Symbol	Min.	Typ.	Max.	Unit	Note
Storage Temperature	Ts	-40	-	85	ºC
Relative Humidity	RH	5	-	95	%
Power Supply Voltage	VCC	-0.3	-	4	V
Signal Input Voltage	VCC	Vcc-0.3	-	Vcc+0.3	V

Recommended Operating Conditions

Parameter	Symbol	Min.	Typ.	Max.	Unit	Note
Case Operating Temperature	Tcase	0	-	70	ºC	Without air flow
Power Supply Voltage	VCC	3.14	3.3	3.47	V
Power Supply Current	ICC	-	-	600	mA
Data Rate	BR	9.95	10.3125	11.3	Gbps
Transmission Distance	TD	2	-	40	km
Coupled fiber	Single mode fiber

Optical Characteristics

Parameter	Symbol	Min.	Typ.	Max.	Unit	Note
Transmitter
Average Launched Power	Pout	0	-	5	dBm
Average Launch power of OFF transmitter	POFF	-	-	-30	dBm	Note (1)
Centre Wavelength Range	λC	1260	1270	1280	nm	LASX-T2733X-ER
		1320	1330	1340	nm	LASX-T3327X-ER
Side mode suppression ratio	SMSR	30	-	-	dB
Spectrum Bandwidth(-20dB)	σ	-	-	1	nm
Extinction Ratio	ER	3.5		-	dB	Note (2)
Output Eye Mask	Compliant with IEEE 802.3ae requirements					Note (2)
Receiver
Input Optical Wavelength	λIN	1320	1330	1340	nm	LASX-T3327X-ER
		1260	1270	1280	nm	LASX-T2733X-ER
Receiver Sensitivity in average	Psen	-	-	-15	dBm	Note (3)
Input Saturation Power (Overload)	PSAT	0.5	-	-	dBm	Note (3)
LOS -Assert Power	PA	-32	-	-	dBm
LOS -Deassert Power	PD	-	-	-18	dBm
LOS -Hysteresis	PHys	0.5	-	4	dB

---
