Product Details
Product Description
Product Description
Pleated Wire Mesh Filter Cartridge Feature
1. Pleated wire mesh filter cartridge has large filter area
2. Pleated wire mesh filter cartridge is surface filtration
3. Pleated wire mesh filter cartridge is good for backwash because the pore passage of wire mesh aperture is very smooth
4. Wire mesh will not shed in filtration process
5. High filter rating accuracy
6. High temperature resistance
7. High corrosion resistance
8. High flow rate
9. Washable and Cleanable
10. Reusable
11. Long service life
Pleated Wire Mesh Filter Cartridge Technical Parameter
Raw Material: SS 316L, SS 304
Filter Rating: 1-300 Microns
Filter Efficiency: > 99.99 %
Operation Temperature: ≤ 816 ℃
Outside Diameter: 50 mm, 60 mm, 63.5 mm, 65 mm, 70 mm, 150 mm, 300 mm, 400 mm or others
Length: 127 mm, 254 mm, 508 mm, 762 mm, 1016 mm or others
Gasket: PTFE, Viton, Silicone, Buna-n, EPDM
Connector:
1. DOE
2. 220
3. 222
4. 226
5. Thread (NPT,BSP,G,M,R)
6. Flange
7. Special customization
Application
Polyester filtration, polymer filtration, high viscosity filtration, fuels and lubricants filtration, oil filtration, steam filtration, high temperature gas filtration, high temperature liquid filtration, steam filtration, potable and process water filtration, beverages filtration, detergent filtration, solvents filtration, pharmaceutical industry, chemical industry, chemical fiber industry, food industry
>>
