20kHz High Quality Ultrasonic Sonicator for Microorganisms Treatment

Product Description

escription: Ultrasonic homogenization is the use of ultrasonic cavitation in liquids and other physical effects to achieve homogenization. Physical action refers to the formation of an effective agitation and flow disrupting medium in the liquid, the pulverizing of the particles in the liquid, mainly the collision between the liquid, the micro phase flow and the shock wave leading to changes in the surface morphology of the particles.
Cavitation refers to the generation of holes (small bubbles) in the weaker part of the liquid under the action of ultrasonic waves. The small bubbles pulsate with the ultrasonic waves, and the holes collapse in one sound cycle. Specifications:

Model	RPS-S20-500	RPS-L20-1000	RPS-S20-1000	RPS-S20-1500	RPS-S20-2000	RPS-S20-3000
Frequency	20Khz	20Khz	20Khz	20Khz	20Khz	20Khz
Power	500 W	1000 W	1000 W	1500W	2000W	3000 W
Voltage	220V	220V	220V	220V	220V	220V
Temperature	150 ºC	150 ºC	150 ºC	300ºC	300ºC	300 ºC
Pressure	Normal	Normal	Normal	35 MPa	35 MPa	35 MPa
Intensity of sound	>10 W/cm²	>10 W/cm²	>10 W/cm²	>30 W/cm²	>40 W/cm²	>60 W/cm²
Max capacity	> 500ml/Min	> 2 L/Min	> 5L/Min	> 15L/Min	> 20L/Min	> 100 L/Min
Material of probe	Titanium Alloy	Titanium Alloy	Titanium Alloy	Titanium Alloy	Titanium Alloy	Titanium Alloy

Applications: Food processingReaction Acceleration - cavitation accelerates chemical and physical reactions.Fine ParticleDispersion - e.g. nanoparticle processingDisruption and Cell Lysing - will break open biological tissues andCells to extract enzymes and DNA, prepare vaccines.This technology provides a method forUltrasonically lysing cells and spores in a liquid flowing continuously or intermittentlythrough a cylindrical reactor.Homogenization - making uniform mixtures of liquids or liquid suspensions.Emulsification - processing foods, pharmaceuticals, and cosmetics.Dissolution - dissolving solids in solvents.Degassing - removing gases from solutions without heat or vacuum.Inline pipe cleaning, removes scale or build/up without disassembly.Cylindrical 360° internally radiating chamber.

Advantages: 1. Core parts with Titanium materials
2. Ultrasonic horn with different size and type for selection
3. Matching with digital generator, auto-tuning, auto search frequency
4. With automatic alarm protection, easy to operate
5. Power adjustable from 1% to 99%
6. Amplitude stability, long working hours, radiation area is increased 2.5 times than
traditional tools
7. Provide consulting services and custom reactor designs
8. Custom sizes available for laboratory and high volume industrial applications

---
