Main battery " Bord I" | |
| Lead-Acid, Gel, AGM Batteries Nominal Voltage | 12V |
| LiFePO4 Nominal Voltage | 12.8V |
| lithium- ion( NCM) Nominal Voltage | 11.1V |
| Capacity (Battery Size), recommended: | 90-560AH |
| Vehicle Starter Battery "Start II": | |
| Vehicle Starter Battery Nominal Voltage: | 12V |
| Min. Battery Capacity (Size), recommended: | 10AH |
| 12 V / 12 V B2B Charging operation | |
| Input Voltage Range "Start II" ,"D+" controlled: | 10.5-16V |
| Maximum charging power: | 780W |
| " Bord I" Max. charge current | 60A |
| Activation Control Input "D+" | 8-16V |
| Signal Output "OK/TR", Switch Position "TR", Cutoff Relay Bypass/max | 12V/1A |
| Signal Output "OK/TR", Switch Position "OK" | 12V/1A |
| Input "T T" for Battery Temperature Sensor "Board I": | YES |
| " Ss-" "Ss+" Inputs Sensor Cables "-" and "+" for Battery "Board I": | YES |
| stand-by current | 24mA |
| Main battery overvoltage protection | 15.5V |
| weight | 1.6kg |
| demension | 190×215×70mm |
| Operating temperature | -20-50ºC |
