Cutting-Edge Perimeter Surveillance Sensor for Human and Vehicle Detection

Product Description

24GHz Millimeter Wave Radar Sensor: Unmatched Security for Perimeter Surveillance with an Astounding 350m Long-Range Detection
Product Description Perimeter Surveillance Radar:
Introducing a revolutionary MIMO technology-based monopulse radar: a low power FMCW marvel. This sensor achieves unparalleled high detection probability, providing precise location and speed data of intrusions, even at ultra-slow speeds. With its smart algorithms and advanced deep learning, it effectively filters out common false alarms induced by environmental elements like trees and bushes. Versatile in application, this radar can function independently or seamlessly integrate into any third-party platform.
Engineered for superior intrusion detection, whether inside or outside physical fences or walls, this perimeter security radar stands out with its MIMO RF antenna design and cutting-edge FMCW signal processing. It delivers exceptional accuracy, resolution, and sensitivity, outputting comprehensive target data such as type, distance, speed, and angle.
Harnessing intelligent AI learning algorithms, this radar expertly differentiates between humans, vehicles, and other entities, substantially minimizing false targets from natural elements like trees and grass. With the ability to customize included and excluded zones through a web interface, it serves as a standalone intrusion detection sensor or connects to third-party alarm devices. The radar can also relay target positions to activate CCTV cameras and integrate into broader security platforms.
In comparison to traditional perimeter security measures, this radar excels across a myriad of adverse weather conditions, including rain, snow, fog, haze, and dust. It reliably reports potential intrusion events with an impressively low false rate, setting a new standard for security.

Features:
--Cutting-edge Radar AI-video technology with a multi-stage decision-making strategy to enhance situational awareness to its fullest potential.
--Utilizes a deep learning algorithm for smart target classification, ensuring precision.
--Employs advanced mmWave MIMO radar for continuous, active monitoring, maintaining vigilance even amidst heavy fog or snow.
--Delivers accurate intrusion detection with a remarkably low false alert rate.
--Provides reliable, all-weather, all-day protection, safeguarding your perimeter at all times.
--Designed with user-friendliness in mind; it's easy to install and operate, ensuring hassle-free use.
Specifications:

Model	TXPR200-P
Radar Type	Frequency Modulated Continuous Wave (FMCW)
Frequency Band	24GHz
Refresh Rate	10Hz
Detection Range (Human)	up to 350m (1148ft)
Detection Range (Vehicle)	up to 500m (1640ft)
Detectable Target Velocity	0.05-30m/s (0.16-98.4ft/s)
Effective Field of View (Horizontal)	±10°
Effective field of view (Vertical)	±6.5°
Simutaneous Tracking	32
Distance Accuracy	±1m (±3.3ft)
Angle Accuracy	±1°
Range Resolution	1.5m (4.9ft)
Alarm Output	NO/NC Relay *1;GPIO *1
Operating System	Built-in Linux
Communication Interface	Ethernet & RS485
Power Supply	DC 12V 2A / POE
Power Consumption	15W
Operating Temperature	-40 ~ 70ºC (-40 ~ 158ºF)
Dimension	300*130*50mm (11.8*5.1*2in)
Weight	1.64kg (3.6lb)
Installation Height	1.5 ~ 4m (4.9 ~ 13.1ft)
Certification	CE, FCC

The sophisticated perimeter security alarm software orchestrates a network of perimeter surveillance terminals, AI-video boxes equipped with security radars, and video surveillance cameras, all underpinned by an integrated smart algorithm. This platform serves as the central hub of the entire perimeter security system. Upon intrusion into the alarm zone, the radar sensor deftly pinpoints the intrusion location through proactive detection, accurately identifying the intrusion type with AI vision. It also captures the intrusion process on video, reporting in real-time to the perimeter security alarm management platform. This ensures comprehensive, three-dimensional monitoring and preemptive warning of perimeter threats.

---
