SAE 100r1at/En853-1sn Single Layer High Pressure Wire Braided Hydraulic Hose

Product Description

SAE 100R1AT/EN853-1SN Single Layer High Pressure Wire Braided Hydraulic HoseProduct Description
Single-layer high-pressure steel wire braided hydraulic rubber hose is aspecialized type of hose used in various hydraulic systems to transmit pressurized hydraulic fluids. Its construction consists of a single layerof high-tensile steel wire braiding wrapped around a sturdy rubber innertube. This design provides the hose with the strength and flexibility required to with stand high-pressure conditions and deliver hydraulicfluids efficiently.
The steel wire braiding acts as a reinforcement layer, enhancing thehose's resistance to internal and external pressures. It helps prevent thehose from bursting or collapsing under high-pressure situations,ensuring a reliable and durable performance in hydraulic applications.
The rubber inner tube serves as the conduit for hydraulic fluid transmission, allowing for seamless flow within the hydraulic system.This inner tube is designed to be compatible with various hydraulic fluids, ensuring that the hose functions effectively in different operating environmentsThe flexibility of the steel wire braided rubber hose allows for easy installation and routing in hydraulic systems. It can bend and maneuver smoothly without kinking or collapsing, facilitating fluid flow and system efficiency. The single-laver high-pressure steel wire braided hydraulic rubber hose plays a crucial role in hydraulic systems by providing a reliable means of transmitting hydraulic fluids under high pressure. Its robust construction, flexibility, and durability make it a key component in ensuring the optimal performance of hydraulic machinery and equipment.
Product Parameters

Pmduct Seiss	Nominal Diameter	Size	(ID)mm		(W.D)mm		(OD)mm	W.P	B.P	Min.B.R	W.T
	mm	inch	min	max	min	max	max	Mpa	Mpa	mm	Kg/m
1SN-03-05	5	3/16"	4.6	5.4	9.0	10.0	12.5	25.0	100.0	90.0	0.19
1SN-04-06	6.3	1/4"	6.2	7.0	10.6	11.7	14.1	22.5	90.0	100.0	0.22
1SN-05-08	8	5/16°	7.7	8.5	12.1	133	15.7	21.5	85.0	110.0	0.27
1SN-06-10	10	3/8"	9.5	10.1	14.5	15.7	18.1	18.0	72.0	130.0	0.34
1SN-08-12.5	12.5	1/2	123	13.5	17.5	19.1	21.4	16.0	64.0	180.0	0.42
1SN-10-16	16	5/8"	15.5	16.7	20.6	22.2	24.5	13.0	52.0	200.0	0.51
1SN-12-19	19	3/4"	18.6	198	24.6	26.2	28.5	10.5	42.0	240.0	0.66
1SN-16-25	25	1"	25.0	26.4	32.5	34.1	36.6	8.8	35.0	300.0	0.96
1SN-20-31.5	31.5	1-1/4"	31.4	33	39.3	41.7	44.8	6.3	25.0	420.0	1.17
1SN-24-38	38	1-1/2"	37.7	39.3	45.6	48.0	52.1	5.0	20.0	500.0	1.50
1SN-32-51	51	2"	50.4	52.0	58.7	61.7	65.5	4.0	16.0	630.0	1.96

Detailed Photos
High Pressure Capability
These hoses are designed to withstand high hydraulic pressures, making them suitable for applications where high pressure is required.Flexibility
Despite the high pressure capacity, these hoses are flexible and easy to bend, allowing for easier installation and use in various applications.Durability
The steel wire braided reinforcement provides added strength and durability to the hose, enhancing its resistance to wear, abrasion, and punctures.Resistance to External Factors
These hoses are resistant to oil, weather, and other external factors, making them suitable for use in harsh environments.Wide Temperature Range
Double-layer high-pressure steel wire braided hydraulic hoses can operate effectively in a wide temperature range, making them versatile for different applications.Company Profile
FAQ
Q1. What are your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have a legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What are your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What are your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and have a good relationship?
A:1. We keep good quality and competitive prices to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.

---
