US$15.00-40.00
|
500 kg
(MOQ)
|
Basic Info.
Model NO.
625/718/600/617/X750/800/825/800h/800ht/925/926
Third Part Inspection
Available
Trade Terms
EXW, Fob, CIF, CFR
Transport Package
Wooden Crate
Specification
As customers′s request
Production Capacity
7000 Tons Per Year
Product Description
1)Alloy 625 has excellent strength at temperatures up to 816°C. At higher temperatures, its strength is generally lower than that of other solid solution strengthened alloys. Alloy 625 has good oxidation resistance at temperatures up to 980°C and shows good resistance to aqueous corrosion, but is relatively moderate compared to other more capable corrosion resistant alloys.
2)N06600 has good resistance to corrosion and high temperature, and has high strength and good fabricability. It resists chloride-ion-incurred stress corrosion cracking, sulfur compounds and oxidizing conditions at high temperatures. 3)Alloy 601 has good resistance to heat and corrosion, especially outstanding to oxidation at elevated temperatures up to 1200°C. It also has high strength, good fabricability and good resistance to aqueous corrosion.
4)Alloy 718 is an age-hardenable Alloy-chromium alloy that combines corrosion resistance with high strength and good fabricability. It has high creep-rupture strength at temperatures up to 700°C. Its excellent relaxation resistance contributes to its application in springs. 5)Alloy X750 is an age-hardenable Alloy-chromium alloy. It has good corrosion and oxidation resistance and high strength at temperatures up to 700°C. It also has good properties down to cryogenic temperatures. Its corrosion resistance performance is similar to Alloy 600. 6)Alloy 020 has excellent resistance in chemicals containing sulfuric acid, and has good resistance to environments containing chlorides, phosphoric acid and nitric acid. It contains niobium for stabilization against sensitization and resultant intergranular corrosion. It also has good mechanical properties and fabricability. 7)N08800 has good rupture and creep strength and excellent resistance to oxidation, carburization and sulfidation at temperatures up to 816°C. It also resists general corrosion by many aqueous media. For applications requiring higher stress rupture and creep properties, especially at temperatures above 816°C,N08810 and N08811are recommended. N08800 is readily formed, welded and machined. 8)N08810 has a restricted carbon content range of 0.05 to 0.10%, which is in the upper portion of that of N08800, and is annealed at 1149 to 1177°C (N08800 is annealed at 983 to 1038°C). These differences impart it to have higher stress rupture and creep properties than N08800. 9)N08811 ensures higher stress rupture and creep properties compared to N08810 as a result of restricting the carbon content further in the range of 0.06 to 0.10% (N08810 is 0.05 to 0.10%), and the aluminum plus titanium content at 0.85 to 1.20% (N08810 is 0.30 to 1.20%). 10)Alloy 825 has excellent resistance to chloride-ion-induced stress corrosion cracking, reducing environments containing phosphoric and sulfuric acids, oxidizing environments containing nitric acid and nitrates, and pitting, crevice corrosion and intergranular corrosion. It has good mechanical properties at cryogenic temperatures to moderately high temperatures up to 538°C. 11)Alloy 926 is a super austenitic stainless steel having excellent resistance to pitting and crevice corrosion in media containing halides and hydrogen sulfide. It also has outstanding resistance to chloride-induced stress corrosion cracking, and resists to both oxidizing and reducing environments
12)Alloy 925 is a precipitation-hardenable Alloy-iron-chromium alloy. It combines high strength with Alloy 825's excellent corrosion resistance. Alloy 925 is particularly resistant to sulfide-induced stress cracking and stress-corrosion cracking. 13)Alloy 617 has excellent resistance to oxidation and carburization at high temperatures. It also resists a wide range of corrosive aqueous environments. Alloy 617 has high strength and maintains much of its strength at elevated temperatures. CHEMICAL COMPOSITION
| | C | Mn | Fe | P | S | Si | Cu | Ni | Co | Al | Ti | Cr | Nb+Ta | Mo | B | N | W | La | V | Nb |
| Inconel 600 | ≤0.15 | ≤1.0 | 6.0-10.0 | ≤0.015 | ≤0.015 | ≤0.5 | ≤0.5 | ≥72.0 | -- | -- | -- | 14.0-17.0 | -- | -- | -- | | | | | |
| Inconel 601 | ≤0.1 | ≤1.5 | balance | ≤0.02 | ≤0.015 | ≤0.5 | ≤1.0 | 58.0-63.0 | -- | 1.0-1.7 | -- | 21.0-25.0 | -- | -- | -- | | | | | |
| Inconel 625 | ≤0.1 | ≤0.5 | ≤5.0 | ≤0.015 | ≤0.015 | ≤0.5 | -- | ≥58.0 | ≤1.0 | ≤0.4 | ≤0.4 | 20.0-23.0 | 3.15-4.15 | 8.0-10.0 | -- | | | | | |
| Inconel 617 | 0.05-0.15 | ≤1.0 | -- | ≤0.012 | ≤0.015 | ≤1.0 | ≤0.5 | ≥44.5 | 10.0-13.0 | 0.8-1.5 | ≤0.6 | 20.0-24.0 | -- | 8.0-10.0 | | | | | | |
| Inconel 690 | ≤0.05 | ≤0.5 | 7.0-11.0 | -- | ≤0.015 | ≤0.5 | ≤0.5 | ≥58.0 | -- | -- | -- | 27.0-31.0 | -- | -- | -- | | | | | |
| Inconel 718 | ≤0.08 | ≤0.35 | balance | ≤0.015 | ≤0.015 | ≤0.35 | ≤0.3 | 50.0-55.0 | ≤1.0 | 0.2-0.8 | 0.65-1.15 | 17.0-21.0 | | 2.8-3.3 | ≤0.06 | | | | | 4.75-5.5 |
| Inconel 725 | ≤0.03 | ≤0.35 | | ≤0.015 | ≤0.010 | ≤0.20 | | 55.0-59.0 | | | | 19.0-22.5 | | 7.0-9.5 | | | | | | |
| Inconel 750 | ≤0.08 | ≤1.0 | 5.0-9.0 | -- | ≤0.01 | ≤0.5 | ≤0.5 | ≥70.0 | ≤1.0 | 0.4-1.0 | 2.25-2.75 | 14.0-17.0 | 0.7-1.2 | -- | -- | | | | | |
| Inconel 20 | ≤0.07 | ≤2.0 | balance | ≤0.045 | ≤0.035 | ≤1.0 | 3.0-4.0 | 32.0-38.0 | -- | -- | -- | 19.0-21.0 | 8*C-1 | 2.0-3.0 | -- | | | | | |
| Inconel 28 | ≤0.02 | ≤2.5 | balance | ≤0.02 | ≤0.015 | ≤1.0 | 0.6-1.4 | 30.0-34.0 | | | | 26.0-28.0 | | 3.0-4.0 | | | | | | |
| Inconel 925 | ≤0.03 | ≤1.0 | balance | ≤0.03 | ≤0.03 | ≤0.5 | 1.5-3.0 | 42.0-46.0 | -- | 0.15-0.5 | 1.9-2.4 | 19.5-23.5 | -- | 2.5-3.5 | -- | | | | | |
| Inconel 926 | ≤0.02 | ≤2.0 | balance | ≤0.03 | ≤0.01 | ≤0.5 | 0.5-1.5 | 24.0-26.0 | -- | -- | -- | 19.0-21.0 | -- | 6.0-7.0 | -- | 0.15-0.25 | | | | |
| Inconel 825 | ≤0.05 | ≤1.0 | balance | ≤0.02 | ≤0.03 | ≤0.5 | 1.5-3.0 | 38.0-46.0 | -- | ≤0.2 | 0.6-1.2 | 19.5-23.5 | -- | 2.5-3.5 | -- | | | | | |
| Inconel 800 | ≤0.1 | ≤1.5 | balance | -- | ≤0.015 | ≤1.0 | ≤0.75 | 30.0-35.0 | -- | 0.15-0.6 | 0.15-0.6 | 19.0-23.0 | -- | -- | -- | | | | | |
| Inconel 800H | 0.05-0.1 | ≤1.5 | balance | | ≤0.015 | ≤1.0 | ≤0.75 | 30.0-35.0 | -- | 0.15-0.6 | 0.15-0.6 | 19.0-23.0 | -- | -- | -- | | | | | |
| Inconel 800HT | 0.06-0.1 | ≤1.5 | balance | | ≤0.015 | ≤1.0 | ≤0.75 | 30.0-35.0 | | 0.15-0.6 | 0.15-0.6 | 19.0-23.0 | | | | | | | | |
THE MINIMUM MECHANICAL PROPERTIES AT NORMAL TEMPERATURE
| Alloy and State | Tensile Strength | Yield Strength | Rate of Elongation | Brinell Hardness |
| Rm N/mm2 | RP0.2N/mm2 | A5% | HB |
| Inconel 600(Outside Diameter≥127) | ≥550 | ≥205 | ≥35 | - |
| Inconle 600(Outside Diameter≤127) | ≥550 | ≥240 | ≥30 | - |
| Inconel 601 | ≥550 | ≥205 | ≥30 | - |
Inconel 625
Solid Solution | ≥690 | ≥276 | ≥30 | ≤220 |
Inconel 625
Annealing | ≥827 | ≥414 | ≥30 | - |
| Inconel 690 | 700 | 350 | 35 | ≥85 |
Inconel 718
(Solution Treatment) | <965 | 550 | 30 | ≤363 |
Inconel 718
(Solution + Aging) | ≥1275 | ≥1034 | ≥12 | ≥331 |
| Inconel 750 | 1170 | 790 | 10 | 302-363 |
| Inconel 20 | 551 | 241 | 30 | - |
| Inconel 28 | ≥500 | ≥215 | 40 | ≤155 |
| Inconel 617 | 680 | 300 | 30 | - |
| Inconel 925 | 650 | 300 | 30 | - |
| Inconel 926 | 650 | 295 | ≤35 | - |
| Inconel 825 | 586 | 241 | 30 | - |
| Inconel 800 | 520 | 205 | 30 | - |
| Inconel 800H | 450 | 170 | 30 | - |
| Inconel 800HT | 450 | 170 | 30 | - |
>>
