Product Details
Product Description
Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
This chapter contains an overview of the SCXI-1141/1142/1143 module and explains the operation of each functional unit of the module. The SCXI-1141/1142/1143 module has eight software-controlled input channels that amplify and filter signals. Each channel has an output range of ±5 V and has an input amplifier with gains of 1, 2, 5, 10, 20, 50, and 100. You can independently set each amplifier gain. The analog inputs are overvoltage protected. The SCXI-1141/1142/1143 module filters are lowpass, 8th-order elliptic, Bessel, and Butterworth filters respectively that can have a cutoff frequency from 10 Hz to 25 kHz. All eight filters have the same cutoff frequency. The outputs of all eight channels are available at the rear connector. The major components of the SCXI-1141/1142/1143 module are as follows: • Digital control and calibration circuitry • Input amplifiers • Lowpass filters Power-Up State When the SCXI-1141/1142/1143 module is powered up or reset through software or the SCXI chassis reset button, the following states are defined: • The gain of each amplifier is set to 1. • Channel 0 is selected as the OUTPUT signal and the module defaults to multiplexed mode. • All filters are placed in bypass mode. • The external clock input is disabled. The cutoff frequency of the filters and the output clock frequency are not defined at power-up. The block diagram in Figure 4-1 illustrates the key functional components of the SCXI-1141/1142/1143 module.
>>
