High-Performance Tck66A Slant Bed CNC Lathe Machine for Metal Price List

Product Description

High-Performance TCK66A Slant Bed CNC Lathe for Metal Price
Standard configurations:
GSK988T CNC controller,
Taiwan linear guide way,
High spindle unit speed 3000rpm, 11kw servo motor,
10" hollow type hydraulic chuck
8 station hydraulic turret ,
hydraulic tailstock
automatic lubrication system,
automatic cooling system,
work light ,
tools & tool box


Optional configurations:
Chip conveyor
Siemens or FANUC CNC controller

Model	Unit	TCK66A
Max. swing over bed	mm	660
Max. swing over slide	mm	400
Max. processing length	mm	700
Max. bar capacity	mm	75
Max. processing diameter (disc type workpiece)	mm	500
Spindle nose	-	A2-8
Spindle bore diameter	mm	85
Spindle speed	rpm	0-2800
Main spindle motor power	kw	11/15
Chuck size	inch	hydraulic 10 inch
X/Z-axis rapid traverse	mm	24/24
X/Z-axis servo motor torque	Nm	10/10
X/Z-axis travel	mm	260, 800
Guide way type	-	linear guide way
Toolpost type	-	horizontal 8/12 station
Tool shank size	mm	25x25, 32
Tailstock type	-	hydraulic tailstock
Tailstock quill diameter	mm	100
Tailstock quill travel	mm	700
Tailstock quill taper	-	MT5
Overall dimension	mm	3700x2000x2000
Machine weight	kg	5000

TENGZHOU BETA CO.,LTD. is a highly reputed professional Machine Tool manufacturer and exporter in CHINA. We focus on complete seals solution include seal making CNC machine, seal processing software, seal materials and cutting tools, the annual output quantity up to more than 1000 units.
Having focused on international market. We have placed the priority on both machines' quality and service. All machines will thoroughly follow every stage during manufacturing, assembling, final testing, packing and shipping, we promise that every provided machine will be strictly tested and be ready to operate before delivery.

---
