High Efficiency HEPA Filter HVAC Air Supply Outlet Vent Diffuser Unit, HEPA Air Filter, Air Filter

Product Description

Mini fold gel seal (large dust capacity) Filter liquid seal (H13, H14) HEPA ULPA filter for better sealing performance
>Mini-pleat supply outlet (only applicable to top air supply):

Model	Overall size of box body B×A×H (mm)	Filter size (mm)	Rated airfow (m3/h)	Inlet duct (mm)	Air duct connection size ExF(mm)	Overall size of box body T×S×R (mm)	Ring spacingP (mm)	Weight (kg)
Side air supply
GKF320F	370 x 370 x 220	320 x 320 x 80	360	200 x 200	250 x 250	430 x 430 x 268	344 x 344	≈ 12
GKF350F	400 x 400 x 220	350 x 350 x 80	450	200 x 200	250 x 250	460 x 460 x 268	374 x 374	≈ 14
GKF484F	534 x 534 x 220	484 x 484 x 80	800	320 x 200	370 x 250	594 x 594 x 268	508 x 508	≈ 16
GKF610F	660 x 660 x 220	610 x 610 x 69	1000	320 x 250	370 x 300	720 x 720 x 268	634 x 634	≈ 18
GKF820F	870 x 650 x 220	820 x 600 x 69	1300	320 x 250	370 x 300	930 x 710 x 268	844 x 624	≈ 20
GKF630F	680 x 680 x 220	630 x 630 x 80	1500	320 x 250	370 x 300	740 x 740 x 268	654 x 654	≈ 22
GKF726F	776 x 534 x 220	726 x 484 x 80	1200	400 x 200	450 x 250	836 x 594 x 268	750 x 508	≈ 22
GKF915F	965 x 660 x 220	915 x 610 x 69	1500	500 x 250	550 x 300	1025 x 720 x 268	939 x 634	≈ 24
GKF968F	1018 x 534 x 220	968 x 484 x 80	1700	500 x 200	550 x 250	1078 x 594 x 268	992 x 508	≈ 32
GKF1220F	1270 x 660 x 220	1220 x 610 x 69	2000	500 x 200	550 x 250	1330 x 720 x 268	1244 x 634	≈ 34
GKF945F	995 x 680 x 220	945 x 630 x 80	2150	500 x 250	550 x 300	1055 x 740 x 268	969 x 654	≈ 32
GKF1260F	1310 x 680 x 220	1260 x 630 x 80	3000	600 x 250	650 x 300	1370 x 740 x 268	1284 x 654	≈ 37

Note: Air filters of different specifications and models can be customized according to users' requirements.
>We have advanced production and test equipment
>Certificates and test reports
>More than 5 years export experience
>Professional packaging and container loading
Packaging is very important, especially for cardboard frame disposable filters and HEPA filters with glass fiber filter media. So we're very careful about that. >FAQ
Can the product be customized?
Yes, the products and packaging can be customized.
How to pay?
Our company accepts various payment methods, such as T/T, L/C, etc. What is the lead time?
7-10 days after payment; 12-15 days for bulk goods
Have you arranged the shipment?
1. Yes, we can arrange the delivery according to the customer's requirements
2. Bulk goods by air or sea, full container; Airport/port reception;
How about after-sales service?
Our company is responsible for the products provided during their useful life.

---
