| US$100.00-5,000.00 | 1 Piece (MOQ) |
| Material: | High Quality Stainless Steel 304 or 316L |
| Design Pressure: | ATM~0.5 Mpa |
| Work Temperature: | 140 °C |
| Volumes: | 100~30000L |
| Structure: | Single-layer, Dual-layer with Jacket and Three-Layer with Insulation and Jacket |
| Insulation/Cooling Function | Sometimes, the tanks will need to be jacketed for heating or cooling. the jacket can be whole jacket, coil jacket or dimple jacket. it will be made of ss304. |
| Motor: | ABB, Siemens, SEW which have the best quality and service all over the world. |
| Voltage/phase/cycle: | 220v/single phase/50hz;220v/ three phase/60hz;380v/ three phase/50hz, it can be required by your special demand. |
| Surface Finish: | Mirror Polish or 2B exterior shell |
| Configuration: | Manhole,CIP Cleaner,Thermometer,Liquid lever meter and controller ,Sanitary breathing cover,Mixer;motor,Inverter etc |
| Applications: | Wine Industry,Food & Beverage,Medicine,Chemical Industry etc |
| Technical Parameters: | 1.This apparatus was manufactured and tested under the standard of JB4735-1997, This apparatus meet GMP standard 2. All wled-seam are argon arc welded,Double weld-seam protect 3. Maximum corrosion resistance 4. Sanitary Tank,No No Dead Corner, Internal and Outside surface polishing, attachment Ra<0.4um 5. Holding 2 hours under full water pressure test, no leakage 6. Quality Guarantee Period: One Year |
| Parameter | ZT 300 | ZT400 | ZT500 | ZT600 | ZT1000 | ZT2000 | ZT3000 | ZT5000 | ZT10000 | |||||||||||||
| Cubage(L) | 300 | 400 | 500 | 600 | 1000 | 2000 | 3000 | 5000 | 10000 | |||||||||||||
| Pressure | Internal bladder | ≤ 0.2Mpa | ||||||||||||||||||||
| Insert set | ≤ 0.3Mpa | |||||||||||||||||||||
| Power (Kw) | 0.55 | 0.55 | 0.75 | 0.75 | 1.1 | 1.5 | 1.5 | 2.2 | 3 | |||||||||||||
| Speed of impeller | 18=200r/min | |||||||||||||||||||||
| Outlook size (mm) | Diameter | 900 | 1000 | 1150 | 1150 | 1400 | 1580 | 1800 | 2050 | 2500 | ||||||||||||
| Height | 2200 | 2220 | 2400 | 2500 | 2700 | 3300 | 3600 | 4200 | 5000 | |||||||||||||
| Heat transfer area | 2 | 2.4 | 2.7 | 3.1 | 4.5 | 7.5 | 8.6 | 10.4 | 20.2 | |||||||||||||
