Low Current Rb Robort DC Pm China Step Motor

Product Description

Low current rb robort dc PM china step motor
Produce show
Specification of Low current rb robort dc PM china step motor

42BY PM Stepper Motor
Basic Information
Item			Data
Tem. Rise			50K max
Working Tem.			(-20ºC~+80ºC)
Insulation Resistance			100MΩ min 500VDC
Surge Test			500VAC for 1min
Insulation Class			E
Weight			60g

Specification
PN	Step Angle	Voltage	Current	Resistance	Inductance	Drive in torque	aligning torque	Starting Frequency	Rotate Frequency	Noisy Level
	(°)	V DC	mA	Ω	mH	g.cm(200pps)	g.cm	pps	pps	db
42BY46-100-4	7.5	24	250	100	125	80	60	500	600	30
42BY46-30-4	7.5	12	250	30	42	80	60	500	600	30
42BY46-100-4	15	24	250	100	125	80	60	500	600	30
42BY46-30-4	15	12	250	30	42	80	60	500	600	30
42BY412-100-6	3.75	24	250	100	125	70	50	500	600	30
42BY412-30-6	3.75	12	250	30	42	70	50	500	600	30
42BY412-100-6	7.5	24	250	100	125	70	50	500	600	30
42BY412-30-6	7.5	12	250	30	42	70	50	500	600	30

Drawing of Low current rb robort dc PM china step motor
About our company
Probond motors designs brush, brushless, stepper, hysteresis and linear motors to meet customers requirements.
Our motors use standard and special components with customer selected torque/speed requirements that can be modified to your applications.
Probond motor owns professional sales team and engineer team with more than 10 years experience in motor industry, based on China mainland handling overseas business for years, we know your needs better than others.
Probond Sonicare Toothbrush Motor and Thermostatic Valve Hysteresis Motor are our hot products on sell in 2017 with highly quality level and competitive price.
Shipping&Payment

Terms of price	FOB,CIF,CFR,EXW,DDP,etc.
Terms of payment	100% T/T in advance for samples
	Bulk quantity payment way can be negotited
Warranty	12 months limited warranty once the items are delivered to the buyer.
Lead time	Usually within 2 weeks for trial orders, within 3 weeks for bulk orders.
Package	Carton o plywood pallet.
Place of loading	Shanghai, Ningbo, etc.
Shipment carrier	Items are usually shipped via Fedex,DHL,TNT,UPS,EMS for trial orders and via vessel for bulk orders.
Delivery time	Usually within 5 working days by Express

---
