| Environment Temperature | -40°C~90°C |
| Anti-wind capability | 32m/s |
| Diameter | 60cm |
| Weight | 6kg-10kg |
| Color | Red or customized |
| Application | For overhead powerline |
| Ingress Protection | IP65 |
| 1.Very suitable for overhead powerline near airport,supper high voltage(above 220kV) powerline and cross-river transmission powerline. | |
| 2.Selected raw material,including high quality fiberglass,resin etc.Ensure the material could be anti-corrosion,high temperature resistance,insulating,anti-rust,anti-dust,water-proof and strong anti-shock. | |
| 3.Customized Color,including White/Red/Orange/Orange and White dual color/Orange and Red dual color etc. | |
| 4.Fast and easy to install,fixed on powerline without any later maintaining | |
| 5.Has anti-interference ability,but doesn't influence the high-voltage line normal operation. | |
| 6.Good adaptability,its' performance doesn't change under complex climate such as wind,frost,rain,snow,high temperature etc. | |
| SPHERE600-O-Ø12,5-18,5 Part Number 113655O125 The obsta spherical markers are compliant with International Civil Aviation Organisation (ICAO) annex 14 chapter 6 recommendations. They are used for day marker for meteorogical towers (guyed structures), ground cable on transmission lines etc SPHERE600-O-Ø12,5-18,5 overall diameter 600mm material: polyethylene clamps suitable for ground cable or OPGW color: white, red or aviation orange as per ICAO (annex 14 chapter 6 of International Civil Aviation Organisation) designed for ground cable, OPGW cable, guy wires etc easy and quick assembly with 6 nuts only to clamp it to the cable 8 drain holes per sphere | |
