Brass, Cast Iron or Forged Stainless Steel Electric & Pneumatic Industrial Floating Ball Valve with Thread / Screw NPT or Bsp Ends

US$145.00 1 Piece (MOQ)

Basic Info.

Model NO.

Q41F

Driving Mode

Manual

Nominal Pressure

ANSI CLASS 150-900

Channel

Straight Through Type

Structure

Floating Ball Valve

Type

Floating Ball Valve

Function

Blow-Down Valve

Temperature

Normal Temperature

Application

Industrial Usage, Water Industrial Usage, Household Usage

Size

1/2"~6"

Pressure

150lb-900lb

Approved by

Ce, ISO

Ball Type

Floating Ball Valve

Body Material

Stainless Steel Ball Valve

Design

API 6D / ASME B16.34

Pre. & Tem. Rating

ASME B16.34

Face to Face

ASME B16.10

End Connection

ASME B16.5

Test & Inspection

API 598 / API 6D

Transport Package

Sea Worthy

Specification

API, ANSI, ASME, BS, DIN, JIS, GB etc.

Trademark

VATAC or OEM

Origin

China

HS Code

84818010

Production Capacity

6000TON per Year

Product Description

Cast Iron or Forged Stainless Steel Electric & Pneumatic Floating Ball Valve with Screwed NPT or BSP Ends Conform to API 6D, BS5351, and ASME B16.34, They are tested according to API 598, and marked as per MSS SP-25.
1. Construction is as follows:
- Full Port or Reduce Port
- Split Body
- Bolted Bonnet with spiral-would gasket
- Fire Safe Design
- Anti-static Design & Blow-out proof stem
- Double seat structure
- Butt Weld Ends to ASME B16.25
- Flanged Ends to ASME B16.5
2. Main Part & Materials

Part Names	Part Materials
Body	A105	LF2	F22	F304	F316	F304L	F316L
Bonnet	A105	LF2	F22	F304	F316	F304L	F316L
Ball	A105+ENP	SS304	F22	SS304	SS316	SS304L	SS316L
Stem	A105	F304	F6a	F304	F316	F304L	F316L
Seat/Seat Ring	13%Cr	SS304	13%Cr	SS304	SS316	SS304L	SS316L
Packing	Graphite/PTFE
Gasket	SS304+Graphite/SS304+Graphite
Bolts/Nuts	B7/2H	L7/4	B16/4	B8/8	B8M/8M	B8/8	B8M/8M
Suitable Medium	W.O.G etc.			HNO3, CH3OOH etc.
Suitable Temperature	-29~425 °C	-46~340 °C	-46~340 °C	-196~427 °C	-196~427 °C	-196~427 °C	-196~427 °C

3. Normal Pressure Rating
PN10~PN420, CLASS150~2500
4. Normal Size Range
DN50~DN1000, 2"~40"
5. Pictures
Final Inspection
Shipment
