Basic Info.
Type
Drum Drying Equipment
Application
Grain/Sand/Sludge
Operating Pressure
Vacuum
Roller Number
Single Drum
Automatic Grade
Automatic
Video Outgoing-Inspection
Provided
Material
304 Stainless Steel
Core Components
Motor,Engine
Product Name
Multifunctional Drum Dryer
Key Selling Points
High-Accuracy
Transport Package
Standard Export Wooden Case
Specification
3800*1000*1450mm
Production Capacity
2000 Sets/Year
Product Description
MTN Sand Chicken Manure Dryer Machine Rice Maize Dryer Machine Corn Grain Rotary Drum Dryer Price Product Description
Introduction
Grain drum dryer uses the rotary convection drying process to efficiently dry grains using heat sources and ventilation systems. It is easy to operate, highly applicable, can quickly reduce grain moisture, and ensure grain quality. It is an indispensable and important equipment in agricultural production.
Application
It can be widely used in drying materials in the fields of river sand, sludge, coal slime, sawdust, sand, tofu dregs, chicken manure, organic fertilizer, feed, etc.
Features
1. With hot air as the drying medium and a circulating drying process, the material is evenly and fully heated and hydrated, and the quality is good after drying.
2. The heating system is relatively advanced, and the material is dried after heat energy conversion.
3. Equipped with automatic online temperature and humidity measurement devices, the degree of automation is greatly improved, and the drying uniformity is high.
4. The working process can be automatically controlled, the machine can be automatically shut down, the operation is simple, labor is saved, and labor costs are greatly reduced.
Structure
Parameters
| Model | Dimensions of the drum (Including feeder) | Power (KW) | Heating power (KW) | Wetted fan(W) | Reducer | Overall dimensions(mm) |
| MTN-200 | 800*1800*3mm | 1.5 | 30 | 370 | / | 3000*1000*1450 |
| MTN-300 | 800*2600*3mm | 2.2 | 30-40 | 370 | ZQ200 | 3800*1000*1450 |
| MTN-500 | 1000*2800*3mm | 3.0 | 40-50 | 370 | ZQ250 | 4200*1200*1600 |
| MTN-1000 | 1200*3400*4mm | 4.0 | 60-80 | 550 | ZQ250 | 4800*1500*1700 |
| MTN-2000 | 1500*4400*5mm | 7.5 | 80-100 | 750 | ZQ350 | 6000*1800*2100 |
| MTN-3000 | 1500*6000*5mm | 11.0 | 120-150 | 1100 | ZQ350 | 7800*1800*2100 |
| MTN-5000 | 1800*6600*8mm | 15.0 | 180-200 | 1500 | ZQ500 | 9300*2300*2500 |
Detail Display
Product Photograph
>>
