Trailer Turntable Ballrace Turntable Slewing Ring Rotating Ring

Product Description

UT Truck Trailer Turntable
Single row ball bearing turntables are for trailers and agricultural vehicles, connecting the A-frame to the trailer chassis. The turntable allows the axle to turn relative to the trailer frame transferring both the axial, and radial forces. The lower (outer) ring is bolted to the A-frame and the upper ring (inner) ring is bolted to the chassis.
Double row ball turntables guarantee optimum distribution of the axial and radial forces. This design has proven through years of different applications. Double row ball turntables are used in particular when the vehicle application requires both precision and strength in design and material.
Products details:
As per the production technology, there are casting turntable, forging turntable and casting steel turntable.
As per the Bearing, there are single ball bearing turntables, double ball bearing turntable, and three ball bearing turntable.
As per the shape, there are UA type turntable, UB type turntable, C type turntable and D type turntable.
Also we manufacture different types Drums, Hubs and other Casting Parts in this factory.

Type	Part No.	A	B	E	F	H	Capacity	Weight	Related To
		mm	mm	mm	mm	mm	ton	kg
UA02	UT1000-70UA02	1000	1000	846	879	70	8	77	1000X70
	UT1000-90UA02	1000	1000	846	879	90	8	68	1000X90

Type	Part No.	A	B	E	F	H	Capacity	Weight	Related To
		mm	mm	mm	mm	mm	ton	kg
UA03	UT1008-90UA03	1000	1008	886	849	90	10	78	SB1000-22LW
	UT1100-90UA03	1095	1108	986	949	90	12	86	1100-22
	UT1200-90UA03	1195	1208	1086	1050	90	13	95	1200-22
	UT1211-90UA03	1200	1211	1083	1050	90	13	95	1211-22
	UT1315-90UA03	1300	1315	1180	1146	90	14	107

Shandong UT Trailer Parts Co., Ltd., is a professional manufacturer of semi trailer's spare parts. It possesses production buildings of more than 12000 meter square, and senior and intermediate staffs more than 60 technicians' team. Our products are strictly been produced and examed by ISO9001: 2000 International Quality Management System.
We've been exploited overseas market continuously, and established sale and after service net spot in nation scope. It is our eternal pursuit that "the first class products, reasonable price, the perfect after service".

---
