50tpd Flour Milling Line 50ton Per Day Wheat Flour

Product Description

Product Description

50tpd flour milling line 50ton per day wheat flour making machine Main Systems
Pre-cleaning section
Cleaning section
Milling Section
Packing Section
Control Section
50tpd flour milling line 50ton per day wheat flour making machine Other systems:
The raw material storage system
Condition bin system
Air Compressor system
Dust collection system
Auto packing system
PLC Control system

50tpd flour milling line 50ton per day wheat flour making machine
	ITEM	Specification	Note
1	Power	150kw	Different design according to Clients' inquiry
2	Space inquiry	36M*8M*7.5M	LWH Consider the space for flour storage
3	Container inquiry	3 pieces	40feet container*2+20feet container*1
4	Installation Issue	60days	Including machine installation guide, test and trainning local worker
5	Spare parts	2years free
6	Extra rollers	Included	according to different design

50tpd flour milling line 50ton per day wheat flour making machine,We can supply the design and manufacture the machine line with the capacity from 5T/24H to 500T/24H.
Our machine line include clean part, flour milling part and packing part.
1. The flour cleaning part:
Includes beating, screening, destoner, magnetic separator and dampening. Different capacity machine line has different number of beat, screen and stoner.
To ensure the flour Quality and the working life of the mill by removing the impurities in the wheat before go to mill,
Beat: through the beat function of the wheat scourer, wheat brusher to remove dust sand small seed, bacterial count and insect seed.
Screening: to remove large and small impurities in the wheat seed by make the wheat go through vibrating sieve and aspiration sieve.
Destoner: mainly remove stone in the wheat to protect them milled into the flour and also protect the roller on the milling process.
Magnetic separator: remove metal material in the wheat to keep the roller safe and also avoid flour exploration accident of spark caused by the impact of the metal impurities and the machine.
Dampening: Washing machine or stainless steel damper
2.The flour milling part:
Include different number of mill and sifter to mill the wheat and separate the flour and bran
(1) Mill: mill the wheat to break the integrity by the roller moving
(2) Sifter: to separate the flour and bran, also separate large size and small size to enssure flour quality.
(3)Final sifter checker: Sigle sifter check the flour quality
3. Packing part.
The packing part can be manual one also can be auto, this can be designed according to requirement and machine capacity.
For PP woven bags auto packing 5kg 10-25kg 25-50kg
paper bags packing 1-5kg
manually 1-50kg
50tpd flour milling line 50ton per day wheat flour making machine Factory Design:
Detailed Photos
The newest technology for each part, the cleaning section-Sifter, the milling section-packing section.
Produce high-quality wheat flour for bread, biscuit, pasta, macaroni, cake etc.
50tpd flour milling line 50ton per day wheat flour making machine Some Advantages as below:
1. Pipes and cyclone in milling section is Stainless steel material.
For food processing line it is industry develepment trend.Life long time and more durable.
2.Auto vibrating feed system Roller mill,with European standard,high quality.
3.Stainless steel Washing machine
4.Smart touch screen control system.new technology and easy control.
5.Purifier is optional part,make quality "semolina " for pasta macaroni etc.
More advantage of 50tpd flour milling line 50ton per day wheat flour making machineContact us now


Packaging & Shipping

Company Profile
Plant cases

Successful cases some as Following:
1500t/24h flour mill in South Africa(China largest export mill line);
1000t/24h wheat flour mill in Australia;
300t/24h wheat flour mill line in Afghanistan;
300t/24h wheat flour mill line in Malaysia;
250t.24h wheat flour milling machine in Egypt;
200t/24h wheat flour mill line in Brazil;
150t/24h wheat flour mill line in Zambia
120t/24h wheat flour mill line in China.
120ton wheat flour milling machine in Ethiopia;
80t wheat flour milling line in Ethiopia
42tpd wheat flour milling machine in Ethiopia
50ton per day wheat flour mill line in Ethoipia
After Sales Service

---
