| US$800.00-2,000.00 | 1 Set (MOQ) |
| Model | D2 | D3 | D4 | |
| Max. drilling diameter(steel) | 25mm (1in) | 25mm (1in) | 25mm (1in) | |
| Max. spindle travel | 140mm (5 1/2in) | 140mm (5 1/2 in) | 140mm (5 1/2 in) | |
| Taper of spindle bore | Morse No. 3 | Morse No. 3 | Morse No. 3 | |
| Distance from the centre of spindle to the surface of the vertical column | 225mm (8in) | 225mm(8 7/8 in) | 315mm(12 3/8 in) | |
| Max. distance from spindle nose to the surface of worktable | 620mm(24 1/2 in) | 660mm(26 in) | ||
| 8Spindle speeds range (8 steps) | 50HZ:100 ~ 2900 rpm , 60HZ:120~3480rpm | 50Hz: 100 ~ 2900 r / min 60Hz:120~3480 r/min | 50Hz: 100 ~ 2900 r / min 60Hz:120~3480 r/min | |
| Feed range of spindle | 0.08,0.16,0.24mm/r | 0.08,0.16,0.24mm/r | ||
| Max. distance from spindle nose to base plate | 445mm(16 in) | 1075mm(42 5/16in) | 480mm(18 7/8in) | |
| Max. distance from spindle nose to working surface of base plate | 400mm | 400mm | ||
| Dimensions of effective working area of worktable | 297×305mm (11×12in) *317×305mm(12×12in) | *Φ340mm(13.4 in) | 315X415mm (12 3/8 X 16 3/8 in) | |
| Dimensions of effective working area of base plate | 297×305mm (11×12in) *317×305mm(12×12in) | 305×297mm (12×11in) *317×305mm(12×12in) | 475X400 mm | |
| Motor power | 0.75 / 0.55 kw | 0.75 / 0.55 kw | 0.75 / 0.55 kw | |
| Overall dimension | 580×470×1000mm (22×18×39in) *590×545×1070mm (23×21×42in) | 640×470×1670mm (25×18×66in) *650×545×1740mm (25×21×68in) | 788X560X1820mm(31X22X72 in) *788X560X1835 (31X22X72.25 in) | |
| Package dimensions (L×W×H) | 740×490×1070mm (29×19×42in) * 750×550×1155mm (29×21×45in) | 1780×510×880mm (70×20×34in) *1860×550×900mm (73×21×35in) | 1900X590X1060mm | |
| N.W / G.W | 170kg/200kg *232kg/270kg | 243kg/299kg *270kg/350kg | 404kg/504kg *430kg/540kg | |
| *3-phase cooling pump | Model | AB12 | DB12 | DB-12 |
| Power | 0.04 kw | 0.04 kw | 0.04 kw | |
| Flow capacity | 12 L / min | 12 L / min | 12 L / min | |
| Specifications | 380V 50Hz | 380V 50Hz/ 22V 60HZ | 380V 50Hz/ 22V 60HZ | |
