850-960 MHz Omni Antenna 8 dBi Gain Spring N Male Connector, Black Fiberglass

Product Description

Product Description
The AAT BLG 0809V6TF is a single band antenna Our vertical polarized antenna with 698 to 2700 MHz frequency range has a N-F(Port can customzied) connectors. This antenna with a black radome made of fiberglass has an overall length of 850cm , a width of 32cm, and a weight of 1.5kg.
cm
L-com's AAT BLG 0809V6TF is a single band antenna operating from 850 to 960MHz with 8dBi gain. The omni directional antenna has a maximum input VSWR of 2:1.
AL ASAR has one of the largest in-stock collections of omni directional antennas with our wide selection of superior quality RF parts, our expert technical support and knowledgeable sales team can help you get the ideal single band antenna as per your requirement.

Performance of electricity index
model	AAT BLG 0809V6TF
Frequency Range (MHz)	850-960
Bandwidth (MHz)	110
gain (dBi)	6
radiation direction	360 degrees omnidirectional
Polarization mode	perpendicular
voltage standing-wave ratio	≤2
input impedence (Ω)	50
maximum power (W)	100

mechanical behavior
Port	N female
Antenna length (mm)	φ32×850
Antenna weight (kg)	1.5
Cover material	Fiberglas (matte black)
working temperature (ºC)	-40~85
Ultimate wind speed (m/s)	60

The AAT BLG 0809V6TF is a single band antenna Our vertical polarized antenna with 698 to 2700 MHz frequency range has a N-F(Port can customzied) connectors. This antenna with a black radome made of fiberglass has an overall length of 850cm , a width of 32cm, and a weight of 1.5kg.
cm
L-com's AAT BLG 0809V6TF is a single band antenna operating from 850 to 960MHz with 8dBi gain. The omni directional antenna has a maximum input VSWR of 2:1.
AL ASAR has one of the largest in-stock collections of omni directional antennas with our wide selection of superior quality RF parts, our expert technical support and knowledgeable sales team can help you get the ideal single band antenna as per your requirement.

---
