| US$55.00-60.00 | 100 Pieces (MOQ) |
| Camera Module No. | KLT-USB-1484 V1 |
| Resolution | 2MP |
| Image Sensor | PS5268 |
| Sensor Type | 1/2.7" |
| Pixel Size | 3.0 um x 3.0 um |
| EFL | 1.86 mm |
| F.NO | 1.86 |
| Pixel | 1920 x 1080 |
| View Angle | 135.0°(DFOV) 124.6°(HFOV) 84.7°(VFOV) |
| Lens Dimensions | 13.20 x 13.20 x 15.72 mm |
| Module Type | Fixed Focus |
| Lens Model | KLT-LENS-1484 V1 |
| Interface | USB 2.0 |
| Output Format | MJPG / YUV2 |
| Auto Control | Saturation, Contrast, Acutance White Balance, Exposure |
| Audio (Optional) | Digital Microphone, Single, Dual Channel |
| Input Voltage | DC 5V |
| Working Current | Max 500mA |
| PCB Size | 32 x 32 mm |
| System Compatibility | Windows XP (SP2, SP3), Vista, 7, 8, 10, 11 Android, Mac OS, Linux or OS with UVC Driver Raspberry Pi by USB Port |
| Software for USB Camera | AMCAP, Webcam Viewer, V4L2 Controls Contacam, VLC Player, MotionEye OS iSpy, ZoneMider, Yawcam |
| Lens Type | 650nm IR Cut |
| Operating Temperature | -20°C to +70°C |
| USB Cable | KLT-Cable-U023 |
