Welcome to visit

Yhzs25 Mobile Commercial Concrete Batching Plants Price

US$50,000.00-100,000.00 1 Set (MOQ)

Basic Info.

Model NO.
YHZS25
Type
Concrete Mixing Plant
Structure
Movable
Productivity
25m²/h
Certification
ISO9001: 2000, CE
Condition
New
Color
White/Blue
Total Power
52kw
Total Weight
23t
Hopper Volume
4X3.5m3
Mixer Model
Js500
Mixer Power
22kw
Transport Package
International Standard Packing
Trademark
S. L MACHINERY
Origin
Fujian, China
Production Capacity
50PCS/Month

Product Description

Function
Our concrete mixing plants can be widely used in construction projects like buildings, roads, bridges, high way roads, municipal projects,docks, airport, water projects, hydropower station,etc. They can also be used in precast concrete unit factories and used as commercial concrete batching plant to sell high quality concrete to different buyers.
Features
1.Reliable mixing quality, high production efficiency, stable and long lifespan;
2.Advanced technology, strict production technique, high safety;
3.Digital weighing, high weighing accuracy, advanced centralized control system, zero repair;
4.Integrated design, flexible layout, space saving, environmental protection;
5.All motors, speed reducers, sensors and other components are of China famous brand.
Technical Data:
Model HZS60 HZS90 HZS120 HZS180 HZS240
Mixer Productivity(m³/h) 60 90 120 180 240
Type JS1000 JS1500 JS2000 JS3000 JS4000
Power(kw) 2x22 2x30 2x37 2x55 2x75
Output(m³) 1 1.5 2 3 4
Aggregate Diameter (mm) ≤800 ≤100 ≤120 ≤150 ≤150
Batching Hopper Hopper Volume(m³) 3X13 4X13 4X15 4X20 4X20
Hopper Quantity 3 4 4 4 4
Belt Conveyor Capacity(t/h) 200 200 300 400 400
Weighing Scope and Accuracy Aggregate(kg) 4×1500±2% 4×2000±2% 4×2200±2% 4×3600±2% 4×3600±2%
Cement(kg) 600±1% 900±1% 1200±1% 1800±1% 2400±1%
Fly-ash (kg) 200±1% 300±1% 400±1% 600±1% 800±1%
Water (kg) 250±1% 400±1% 500±1% 800±1% 1000±1%
Admixture(kg) 20±1% 30±1% 30±1% 50±1% 80±1%
Total Power(kW) 82 108 127 178 220
Discharge Height(m) ≥3.8 ≥3.8 ≥3.8 ≥4 ≥4
Note:
1,The total power excludes the power of screw conveyor;
2,The quantity and volume of hopper can be designed as required;
3,All above specifications are subject to final products.

Accesaries Equipments: Including batching machine, conveyer belts, mixing machine, control room, cement silo and so on.
