Yhzs25 Mobile Commercial Concrete Batching Plants Price

Product Description

Function
Our concrete mixing plants can be widely used in construction projects like buildings, roads, bridges, high way roads, municipal projects,docks, airport, water projects, hydropower station,etc. They can also be used in precast concrete unit factories and used as commercial concrete batching plant to sell high quality concrete to different buyers.
Features
1.Reliable mixing quality, high production efficiency, stable and long lifespan;
2.Advanced technology, strict production technique, high safety;
3.Digital weighing, high weighing accuracy, advanced centralized control system, zero repair;
4.Integrated design, flexible layout, space saving, environmental protection;
5.All motors, speed reducers, sensors and other components are of China famous brand.
Technical Data:

Model		HZS60	HZS90	HZS120	HZS180	HZS240
Mixer	Productivity(m³/h)	60	90	120	180	240
	Type	JS1000	JS1500	JS2000	JS3000	JS4000
	Power(kw)	2x22	2x30	2x37	2x55	2x75
	Output(m³)	1	1.5	2	3	4
	Aggregate Diameter (mm)	≤800	≤100	≤120	≤150	≤150
Batching Hopper	Hopper Volume(m³)	3X13	4X13	4X15	4X20	4X20
	Hopper Quantity	3	4	4	4	4
Belt Conveyor Capacity(t/h)		200	200	300	400	400
Weighing Scope and Accuracy	Aggregate(kg)	4×1500±2%	4×2000±2%	4×2200±2%	4×3600±2%	4×3600±2%
	Cement(kg)	600±1%	900±1%	1200±1%	1800±1%	2400±1%
	Fly-ash (kg)	200±1%	300±1%	400±1%	600±1%	800±1%
	Water (kg)	250±1%	400±1%	500±1%	800±1%	1000±1%
	Admixture(kg)	20±1%	30±1%	30±1%	50±1%	80±1%
Total Power(kW)		82	108	127	178	220
Discharge Height(m)		≥3.8	≥3.8	≥3.8	≥4	≥4
Note: 1,The total power excludes the power of screw conveyor; 2,The quantity and volume of hopper can be designed as required; 3,All above specifications are subject to final products.

Accesaries Equipments: Including batching machine, conveyer belts, mixing machine, control room, cement silo and so on.

---
