Product Details
Product Description
Product Description
Key Features
◆ Adopted 7" 640*480 colorful LCD Touch-screen, Chinese and English version are available, with the guiding menu, easy-operating character.
◆ Simulation tracing and showing the function curve for the temperature rising and testing time, with the wrong operation prompting and change function.
◆ When the temperature is higher than the pre-set value, heating will be stop automatically. The gas will be cut automatically when the measuring is over.
◆ The igniting system adopts the new type of silicon nitride igniter, which is almost similar to the open flame, has he character of reliable repeatability, long operating life.
◆ The gas ignition is optional, which can ignite automatically without the artificial ignition.
◆ With safety function of self-inspection、diagnose、failure warning.
◆ Built-in air pressure sensor, pressure can correct automatically, no need to set the air pressure value.
◆ The local area network data can be transmitted and hardware can be upgraded through RJ45 connector.
◆ Upgrading software and exporting data can be done through the USB connector.
◆ 1000 measuring records can be saved, and if needed, all records can be checked and printed.
Technical Specifications
1. Range: ambient temperature～400℃;
2. Accuracy: Flash point≤110℃: ±1℃
Flash point>110℃: ±2℃
3. Repeatability: Flash point≤110℃: 2℃
Flash point>110℃: 4℃
4. Power consumption: ≤300W
5. Reproducibility: ≤10℃
6. Resolution: 0.1℃;
7. Temperature up rate: Step A, 5-6(℃/min)
Step B 1.0～1.5(℃/min)
8. Ignition type: Automatic electronic ignition, Automatic gas ignition (Optional).
9. Cooling type: Forced cooling.
10. Printing function: Built-in micro thermal printer, manual and automatic print is optional.
11. 1000 measuring records can be saved, and if needed, all records can be checked and printed.
12. Communication function: the digital communication port is optional, which can send test results to LIMS automatically.
13. Power supply: 1) AC(170～264) V, 50/60Hz
2) AC(120±10%) V, (60±1) Hz(Pls specify before ordering)
14. Overall dimension & weight: Controlling part: L270mm×W170mm×H130mm, 2.0kg.
Testing part: L480mm×W245mm×H280mm, 18.0kg.
>>
