| US$2,500.00-5,000.00 | 1 Piece (MOQ) |
| Model | CQ6236 |
| Swing over bed | Φ360mm ( 14 11/64" ) |
| Swing over cross slide | Φ210mm(8 1/4") |
| Swing in gap(D×W) | 480mm×100mm |
| Height of center | 180mm(7 3/32") |
| Distance between centers | 1015 mm |
| Width of bed | 218mm(8 9/16") |
| Max. section of cutting tool | 20mm×20mm |
| Total travel of cross slide | 230mm |
| Total travel of top slide | 120mm |
| Spindle bore | Φ52mm(2 3/64") |
| Spindle nose | D5 |
| Spindle morse taper in nose,in sleeve | M.T6/MT4 |
| Spindle speeds number | 2×9 (18) |
| Spindle speeds range | 65-1800 R.P.M |
| Leadscrew diameter&thread | 24mm×4 T.P.I or pitch 6mm |
| Threads imperial pithches | 4-60 T.P.I |
| Threads metric pithches | 0.4-7mm |
| Longitudinal feeds(imperial/metric) | 0.0021"-0.0508"/0.0527mm-1.2912mm |
| Cross feeds(imperial/metric) | 0.00043"-0.0109"/0.011mm-0.276mm |
| Total travel of tailstock quill | 110mm |
| Tails stock quill | Φ52mm(2 1/64") |
| Taper tailstock quill | M.T #4 |
| Spindle drive motor | 2.0HP |
| Coolant pump motor | 4/75HP(40W) |
| Machine dimension | 1830mm×770mm×1280mm |
| Packing dimension | 1940mm×890mm×1545mm |
| N.W | 680KG |
| G.W | 790KG |
