Functions of Stenter Machines Heat setting is done by the stenter for lycra fabric, synthetic and blended fabric. Width of the fabric is controlled by the stenter. Finishing chemical apply on fabric by the stenter. Loop of the knit fabric is controlled. Moisture of the fabric is controlled by the stenter. Spirility controlled by the stenter. GSM of the fabric is controlled by stenter. Fabric is dried by the stentering process. Shrinkage property of the fabric is controlled. Curing treatment for resin, water repellent fabric is done by the stenter.
| Main Matching Fabric | open width fabric (70~350g/m²) made
of cotton, cotton/polyester,wool,synthtic fiber and
other blended fibers |
| Heat source | natural gas/circulating conduction oil/steam |
| Stentering type | hot air circulating |
| Holding type | pin+clip |
| Chain type | pitch 60mm,oil-free lubricated |
| Rail type | carbon steel+polymer wearing strip |
| Working type | horizontal return chain |
| Working width | 1000-3600mm |
| Working speed | 5-60m/min |
| Chamber Nos | 2-12 |
| Chamber width | 3000mm |
| Insulating board thickness | 150mm |
| Temperature of chamber | 100~220ºC |
| Pinning & brush overfeed ratio | -20%~40% |
| Temp.& Breadth adjustment type | separately adjust on each chamber |
| Capacity of machine | 61.5kw+22.75kw*chamber*Nos |
| Standard machine power supply | 380V/3P/50HZ |
| Control power supply | 220V/24V |
| Steam specification of steam box | 3-6kg/cm² |
| Steam comsuption of steam box | 100-150kg/h |
| Compressed air | 0.35-0.6MPa |
| Total weight | 14T+5.8T/chamber*Nos |
