X6132A Universal Knee Type Milling Machine

Product Description

X6132A Universal Knee Type Milling Machine
(picture for reference only)
Main Characteristics & Application
Model X6132A Universal Knee-type Milling Machine is suit for milling flat, inclined face, angle surface, slots by employing disc cutters, angular cutters, formed cutters and face metal milling cutters. When mounted with the index, the machine will be able to perform milling operations in gears, cutter, helix groove, cam and tub wheel.
The longitudinal, cross and vertical movements of the table can both be operated by hand and power, and it can be rapid moved. Working table and slide ways adopted quality cast hardened ensure high accuracy.

STANDARD EQUIPMENTS:	OPTIONAL ACCESSORIES:
Complete coolant system	2/3 axis DRO
2 sets arbor support	Machine Vice
Halogen machine lamp	Dividing head
Automatic central lubrication system	Rotary table
Cutter arbor φ22 φ27 φ32	Milling chuck
Foundation bolts and nuts	Vertical milling head

Main Specification: (X----longitudinal Y----cross Z----vertical)

Main specification	Units	X6132A
Table size	mm	320×1320
T slots (N×W×D)	mm	3×18×80
Table Load-bearing	Kg	550
Longitudinal travel (Manual/Power)X	mm	800/780
Cross travel (Manual/Power) Y	mm	300/280
Vertical travel (Manual/Power) Z	mm	410/400
Max. rotary angle of table		±45º
Feed speed steps		18 Steps
Feed speed ranges: Longitudinal X	mm/min	15~750
Cross Y	mm/min	15~750
Vertical Z	mm/min	5.7~280
Rapid feed ranges: Longitudinal X	mm/min	2250
Cross Y	mm/min	2250
Vertical Z	mm/min	844
Distance from spindle center to arm	mm	155
Distance between table center to vertical guide way	mm	235-535
Arbor diameter	mm	φ22 φ27 φ32
Min. distance from spindle center to table	mm	30-440
Spindle hole taper		50# 7:24
Diameter of spindle hole	mm	φ29
Spindle speed steps		18 Steps
Spindle speed ranges	r/min	30~1500
Main motor power	kW	7.5
Feed motor speed	kW	1.5
Cooling pump power	kW	0.12
Overall size	mm	2327×1792×1720
Packing box size	mm	2240×1790×2040
Net weight	kg	3300
Voltage/Frequency	V/HZ	380/50

WHY CHOOSE HAVEN BRAND MACHINE:
1) Hihg quality with competitive price
2) 15 years export experience
3) CE,SGS, ISO Certificated
4) OEM SERVICE AVAILABLE
5) 24 HOURS' ONLINE SERVICE (MSN,SKYPE)
6) 14 months quality warranty (after B/L date)
7) Over sea engineers available for problem shooting

Our Target: BRAND HAVEN
High quality;
Assured Delivery;
Vigorous innovation;
Efficient Cooperation;
Noblesse Oblige

---
