DN50 Food Grade Sanitary Hygienic Stainless Steel SS316L Sanitary Tri Clamp Non Retention Strainer Elbow Type Y Filter with Perforated Mesh

Product Description

Product Description
DN50 Food Grade Sanitary Hygienic Stainless Steel SS316L Sanitary Tri Clamp Non Retention Strainer Elbow Type Y Filter with Perforated Mesh
Filter is used to prevent the solid particles from media mixed into the follow-up pipeline facilities.The larger solid particles or impurities will remaining in it after the media is put into proper filter core,as it can reach the request.When surrounding pressure of the filter exceeds demand,or when the filter core is damaged,you can remove the filter,clean or change new filter core,and re-install it.
Filters have a wide range of applications in the food-processing, cosmetics and some chemical industries as well as in auxiliary services of the pharmaceutical industry. They have a hygienic design and are used to filter particles capable of damaging pumps and other equipment

Standard	SMS, DIN
Material Contact Parts	SS304/SS316L (1.4301/1.4404)		Provided with material inspection report
Material Non-contact Parts	SS304 (1.4301)
Seal Material	Silicone, EPDM, FKM, PTFE. All seals material comply with FDA21CFR117.2600
Size	1inch to 6inch, DN25 to DN150
Mesh Size	3Mesh to 400Mesh, 37Micron to 6730Micron, 0.037MM to 6.730MM
Inside Cartridge Filter Screen	Perforated Plate Screen, Wedge Wire Screen, Metal Mesh Screen
Body Combination	Staringht Type, Angle Type, Y Type, Duplex Type
Connection	Butt Weld,Tri Clamp, Male Thread, Female Male Threaded, Union, Weld Thread, Flange
Working Pressure	≤10bar(145psi)
Temperature Range	Minus 20degree Celsius~135degree Celsius
External Surface Treatment	Ra32~64uin (0.8~1.6um)
Internal Surface Treatment	Ra16~32uin (0.4~0.8um)
Warrenty	One Year
Support	OEM, ODM Are Welcome
Application	Milk, Juice, Beer, Beverage, Ect

Drawing & Techanical
Product Parameters
Operating Principle The filter basically consists of a filter body with an inlet and an outlet for the product. The screen is fixed inside the body. The screen retains all particles that are equal or larger than the size of the screen openings.
Materials Filter body AISI316L Gaskets EPDM (according to FDA 117.2600) Internal surface finish Ra < 0,8μm External surface finish mirror polishDesign and Features There are several configurations: - Cleaning of the screen without disassembling the filter:
Angular filter: the inlet and the outlet form a right angle. Y filter: the product enters and leaves the filter in the same direction.
- Cleaning of the screen disassembling the filter: Straight filter: the product enters and leaves the filter in the same direction.
Low pressure drops. DIN 11850 standard connections. Screen with circular (from Ø 0,5 mm to Ø 3 mm) or longitudinal openings (10 x 1 mm).
Technical Specifications
STRAIGHT FILTER / ANGULAR FILTER
Availabale sizes DN 25 - DN 100 (1) 1˝ - 4˝
DN 125 - DN 150 (2) 5˝ - 6˝
Working temperature -10ºC to +120ºC (EPDM) 14ºF to 248ºF
+140ºC (SIP, max. 30 min) 284ºF
Max.working pressure 10 bar 145 PSI
Y FILTER
Availabale sizes DN 25 - DN 50 (1) 1˝ - 2˝
DN 65 - DN 80 (2) 2 ½˝- 3 ½˝
DN 100 - DN 150 (3) 4˝- 6˝
Working temperature -10ºC to +120ºC (EPDM) 14ºF to 248ºF
+140ºC (SIP, max. 30 min) 284ºF
Max.working pressure 10 bar 145 PSI
Options Gaskets in FMP. Connections: DIN, Clamp, SMS, RJT, FIL-IDF, etc. Wedge wire screen cylinder. Heating jacket. Option of filtering from outside to inside of the screen. Double filter.
Advantage of Products1.Each kind of products has strong corrosion resistance and over-long service liftime2.Problem-free welding and assembly and highest possible strenghth
Packaging & Shipping
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
If small order and choose by express , the items are packed by shrink wrap and secondly carton cases.
If heavy weight of cargo ,which be packed by strongly seaworthy ply-wooden cases.
In order to protective items , which will be packed by safety and resistance to shock in ply-wooden cases.
Contact Us
If you have any inquiry or question for our valves, please kindly do not hesitate to let us know soon.
We also produce other valves and pumps, welcome to Xusheng here, we will try our best to quote you in competitive prices.
Company Profile
XUSHENG & COMPASS are manufacturer and supplied with sanitary valves, pumps, pipe fittings, tanks, tube. They are widely used for food, beer, beverage, chemical,biological, pharmacy and so on. Totally 112nos of workers and the factory Covers 4035m2,our warehouse covers 1000m2. We have 29 sets of LG Mazak machines and other CNC machine from Japan ; Meanwhile,we have 2 sets of automatic machining unit. Here is our range of products as below.
A. Sanitary valve includes of butterfly valve, mix-proof valve, division valve, diaphragm valve, ball valve, check valve, safety valve, air relief valve, angle seat valve, constant pressure valve, bottom tank valve, racking arms valve, float valve, breather valve, and so on.
B. Sanitary pumps includes of centrifugal pump, rotary lobe pump, CIP self priming pump, mixing pump, vacuum pump, Emulsion Pump, screw pump, and so on.
C. Sanitary tank component includes of manhole cover, cleaning ball, filter,sight glass.
D. Sanitary pipe fitting has union, ferrule, clamp, solid end cap, pipe holder, nipple, coupling, adapter,elbow, tee, reducer.
E. Sanitary tanks includes of storage tank, mixing tank, fermentation beer tank, and so on.
F. Sanitary tube has seamless and weld type.
14 years experiences in design and good solution in food grade production line.
Competitive prices & High quality products to achieve win-win mutual benefits.
Professional & Communicate easily.
Huge warehouse & Delivering shortly.
Strong team & Better after-sale.
FAQ
Q1. Are you a trading company or factory?We are a manufacturing factory.Q2. What's the payment terms?For small testing orders,we accept Paypal,Western Union,T/T and credit Card.For mass orders,we accept T/T and L/C.Q3.How do you control the quality?Quality control is very important to avoid material mixing and poor quality.We control the quality from beginning to the end.Weonly have 304 and 316L two different materials.100% inspection on raw material.During production,different materials in different place.After materials are finished,we choose 10% for inspection.If there is 0.1% problem in 10%,then no excuse to go ahead for inspecting 100% of the materials.Q4.If there is any quality problem,how do you solve it?We are proud that we never let one customer leave us.We are not 100% perfect,there is some quality problem.We try our best to provide the correct materials in the beginning,so we need less time for quality problem.If there is any quality problem,we take the responsibility.We believe what we are doing together,it will get back tomorrow.If we leave our responsibility,customer will leave us.If we always take our responsibility,we keep our customers with us.Q5.How long is your delivery time?For normal production in 7-10days.For bulk order in 15-25days.Q6.WarrantyOne year warranty for all of our stainless steel products.Gaskets are not included due to the different application for customers.
How to Order ?
How To Order Filters ?
1. Which's material you need, such as SS304 or SS316L ?
2. Which's available size, the size is ranged from 1inch to 6inch, DN25 to DN150 ?
3. Which's combinarion body of filter, such as Y type, Angle Type, Inline Type or Duplex Filter ?
4. What's Connection you need, such as butt weld, tri clamp, male thread ?
5. What's micron or mesh for inside cartridge filter, such as perforated plate screen, wedge wire screen, metal mesh screen ?

---
