Changeable Galvanized Steel C Purlin Roll Forming Machine Price

Product Description

Changeable Galvanized Steel C Purlin Roll Forming Machine Price
Machine's Overview:
Why choose this machine?
1. Certificate: ISO 9001, CE,
2. Lifetime seivices
3. 82mm diameter solid steel shaft. Roller cover with 0.05mm chrome; Lifetime>10years.
4. Introduced Mitsubishi PLC with touch screen to machine controll system.
5. One worker operation (minimum)
6. Heat treatment:Cutting blade. Quenched treatment: Cr12 mould steel cutter
7. Product cut-to-length.
8.Technician overseas installing and training available

Material	Type	galvanized steel sheet
	Thickness(mm)	1.5-3.0mm
Roller material		45#Chrome steel
Forming speed(m/min)		About 15-20m/min
Speed adjusting mode		AC Frequency
Roller drive		Decelerating motor + Chain drive
Cutting mode		Hydraulic cutting
Cutter material		Cr12 mold steel
Length measurement		Encoder
Control mode		Mitsubishi PLC
Operating mode		Button + Mitsubishi Touch screen
Main motor power(kw)		5.5*4 KW (Depend on final design)
Machine weight		About 22000kgs
Machine size		About 12m x 2.10m x 1.65m (Depend on final design)

Components

Decoiler		1set
Feeding & guiding device		1set
Pre-cutting device		1set
Main roll forming machine		1set
Punching equipment		1set
Hydraulic cutting system		1set
PLC Controlling system		1set
Run out table		1set

Process flow:
Decoiling the sheet → Leveling sheet→ Roll forming→ Punching--Measure length and cutting→ the Purlin to the supporter
Controller:
Controller is the "CPU" of forming machine. We choose Mitsubishi PLC from Japan.
With touch screen mode, let your workers enjoy the easy operation;
With auto working mode, let your workers free their hands!


About us
We are professional in making roll forming machines since 2003. Company occupies 6650, in which 5650 for workshops.

1. Capacity: 12-15 sets/month
2. Delivery: in only 5-8 weeks for urgent order
3. Have our own tool center. 12 sets CNC machines.
4. Zhongyuan is a "All-in-house source"
--from raw material to the final high-precision forming machine. We have our precise tooling center.
5. You can rely on our team!
We have engineers with experience more than 15 years in metal forming industry.

Get Free:
"Send" below get profile drawing & design technical support by our 15 year experience technicians FOR FREE!

---
