| Item | Parameters | Description |
| Power Supply | Input voltage | 9~57VDC |
| Input current | Normal: 240mA@12V, max: 800mA@12V | |
| Connection | 5.08mm terminals | |
| Protection | Anti-reverse connection Protection | |
| WAN | Qty | 1 |
| Interface Spec | RJ45,10/100Mbps, Automatically adapted to MDI/MDIX | |
| Protection | ESD ±30kV(contact), ±30kV(air) EFT 40A(5/50ns) Lightning strike 24A(8/20µs) | |
| LAN(POE) | Qty | 3 |
| Interface Spec | RJ45,10/100Mbps, Automatically adapted to MDI/MDIX | |
| POE(optional) | Supports 3 POE power output compatible IEEE802.3at/af Single POE maximum output power 30W With power management function Voltage range 48~57V | |
| Protection | ESD ±30kV(contact), ±30kV(air) EFT 40A(5/50ns) Lightning strike 24A(8/20µs) | |
| Serial Port | Qty | 2 |
| Type | 1 RS485, 1 RS232 | |
| Baud rate | 1200, 2400, 4800, 9600, 14400, 19200, 38400, 57600, 115200, 230400 | |
| Data Bit | 5, 6, 7, 8 | |
| Parity Bit | None, Even, Odd | |
| Stop Bit | 1, 2 | |
| Working mode | Data transparent transmit, Modbus RTU to TCP, Modbus master, Modbus slave | |
| Protection | ESD(contact): 8KV Surge: 4KV(8/20us) ESD ±8kV(contact), ±15kV(air) EFT 4KV, 40A(5/50ns) | |
| Console | Qty | 1 |
| Type | CONSOLE | |
| Interface Spec | RJ45 | |
| Protection | ESD:±8kV(contact), ±15kV(air) | |
| USB (Reserved) | Qty | 1 |
| Type | USB2.0(HOST) | |
| Protection | ESD ±8kV(contact), ±15kV(air) | |
| WIFI | Antenna qty | 2 |
| Antenna type | SMA | |
| Protocol | 802.11a/b/g/n (mixed) | |
| Mode | AP mode, client mode | |
| Frequency | 2.4G | |
| Channel | Channel 1 - 13 | |
| Security | Open, WPA, WPA2 | |
| Encryption | AES, TKIP, TKIPAES | |
| Connection number | 16(Max) | |
| Speed | 300Mbps(Max) | |
| Transmit Distance | Outdoor non-blocking/opening, covering up to 20 meters | |
| SSID Broadcast Switch | Support | |
| Cellular Network | Antenna Port Qty | 1 |
| Antenna Port Type | SMA | |
| 4G(L-E) | GSM/EDGE:900,1800MHz WCDMA:B1,B5,B8 FDD:B1,B3,B5,B7,B8,B20 TDD:B38,B40,B41 | |
| 4G(L- AU) | GSM/EDGE:850,900,1800MHz WCDMA:B1,B2,B5,B8 FDD:B1,B2,B3,B4,B5,B7,B8,B28 TDD:B40 | |
| 4G(L-A) | WCDMA:B2,B4,B5 FDD:B2,B4,B12 | |
| 4G(L-V) | FDD:B4,B13 | |
| 4G(L-J) | WCDMA:B1,B3,B8,B18,B19,B26 FDD:B2,B4,B12 TDD: B41 | |
| 4G(L-CE) | GSM/EDGE:900,1800MHz WCDMA:B1,B8 TD-SCDMA:B34,B39 FDD:B1,B3,B8 TDD:B38,B39,B40,B41 | |
| SIM | Qty | 2 |
| Interface Spec | Drawer interface, supports 1.8V/3V SIM/UIM (NANO) | |
| Protection | In-built 15KV ESD Protection | |
| GPS (optional) | Antenna qty | 1 |
| Antenna type | SMA | |
| Tracking Sensitivity | > -148 dBm | |
| Horizontal Accuracy | 2.5m | |
| Protocol | NMEA-0183 V2.3 | |
| Digital input | Qty | 2 |
| Type | Switch contact signal (dry node) or level signal (wet node) | |
| Range | 1: High level, 5~30VDC, close signal 0: low level 0~1VDC open signal | |
| Pulse frequency | Max 100Hz | |
| Protection | Isolation voltage 3750Vrms | |
| Digital output | Qty | 2 |
| Type | SINK output | |
| Load voltage | Max 50VDC | |
| Load current | 500mA(single), 625mW | |
| Protection | EFT: 40A(5/50ns) | |
| Analog input | Qty | 4 |
| Type | 0~5V,4~20mA,0~20mA | |
| ADC Resolution | 16bit | |
| Protection | EFT: 40A(5/50ns) | |
| Indicator light | ALARM | Alarm indicator light |
| SYS | System running status indicator | |
| 4G | 4G status indicator | |
| WiFi | WiFi status indicator | |
| DO1, DO2 | Digital output indicator light | |
| DI1, DI2 | Digital input indicator light | |
| System | CPU | MIPS CPU, Clock Speed 580Mhz |
| Storage | 16MB (Scalable to 32MB) | |
| RAM | 128MB (Scalable to 256MB) | |
| Software | Network Protocol | PPP, PPPoE, TCP, UDP,DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, SMTP, SSH2, DDNS,SNMP etc. |
| VPN | Ipsec, OpenVPN, L2TP | |
| Firewall | DMZ, DoS defense, IP packet, Domain name and MAC address filtering, port mapping, access control | |
| Remote Management | Support web remote configuration | |
| System Log | Support | |
| Firmware Upgrade | Support serial port local TFTP/web firmware upgrade | |
| Certificate | EMI | EN 55022: 2006/A1: 2007 |
| EMS | IEC(EN)61000-4-2(ESD) IEC(EN)61000-4-3(RS) IEC(EN)61000-4-4(EFT) IEC(EN)61000-4-5(Surge) IEC(EN)61000-4-6(CS) IEC(EN)61000-4-8 | |
| MTBF | 100,000 hours | |
| Others | CE, FCC, ROHS, 3C | |
| Working Environment | Working temperature | -40~85ºC |
| Storage temperature | -40~105ºC | |
| Humidity | 5~95%RH | |
| Others | Enclosure | Metal |
| Size | H145mm * L110mm * W45mm | |
| IP level | IP30 | |
| Net weight | 790g | |
| Installation | Wall-amount/Rail-amount |
