US$25,000.00-40,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Application
Viscous Fluid, Liquid with Suspended Solids, Viscous Fluid
Application Area
Chemical, Daily Chemical, Food, Pharmaceutical, Food
Control System
PLC Control
Main Material
Alloy Steel
Mixing Drum Shape
Conical
Operating Type
Cycle Operating
After-Sales Service
1 Year Free Service and Life Time Service
Construction Material
SS304
Transport Package
Wooden Case
Production Capacity
50 Sets/Year
Product Description
| Model | Total volume, liter | Working volume, liter | Emulsifying motor, kW (*) | Scraper motor, kW (*) | Length (mm) | Width (mm) | Height [closed] (mm) | Height [open] (mm) |
| PVC-8 | 10 | 8 | 2.2 | 0.37 | 1,360 | 1,250 | 1,320 | 1,500 |
| PVC-50 | 70 | 50 | 4 | 0.37 | 1,820 | 1,710 | 1,610 | 1,900 |
| PVC-100 | 125 | 100 | 7.5 | 0.55 | 2,050 | 1,920 | 1,740 | 2,100 |
| PVC-150 | 180 | 150 | 11 | 0.75 | 2,230 | 2,010 | 1,820 | 2,200 |
| PVC-300 | 350 | 300 | 18.5 | 1.1 | 2,810 | 2,180 | 2,030 | 2,500 |
| PVC-500 | 580 | 500 | 30 | 2.2 | 3,110 | 2,580 | 2,320 | 3,000 |
| PVC-1000 | 1,200 | 1,000 | 55 | 4 | 3,270 | 2,850 | 3,250 | 4,000 |
1.kWs are product dependent and might vary.
2.Customized sizes are available against request.
3.All specifications are as accurate as is reasonably possible, but they are not binding.
4.PerMix reserves the right to modify the design without notice.
FAQ
Q: What is your price level compared with European suppliers and local Chinese suppliers?
A: Depending on the machine type and size, our price level is 30%-60% less than the European suppliers and 5-15% higher than the big local suppliers.
Q: Are you able to provide tailor-made design and production for the mixers?
A: Yes, in fact more than half of our mixers are tailor made, which is one of our strong points.
Q: Are you able to design and produce other processing equipment?
A: We are open to discuss about it.
Q: Can you provide machines to OEM customers, meaning to label their brands on the machines.
A: Yes we are doing it a lot. We have several OEM partners in the USA.
Q: Do you have agent network out of China?
A: Yes we do have agents but only in some countries, for example in USA, Germany, Poland, Spain, Denmark, Turkey, Argentina, etc. We are still looking for more agents because we believe to work with agents is the best way to do business.
Q: What is your delivery lead time of the mixing equipment.
A: Depending on the size and level of customization, but usually it is from 6-14 weeks.
Q: How do you pack and ship the mixing machines?
A: For machines don't require full container loading, we will pack them in wooden case. For FCL (full container loading) shipment, we will just wrap the machines in plastic films and fix them in the container. The shipment can be either by air or by sea.
>>
