| Technical specification | Unit | HGS-4080AHD |
| Table size (LxW) | mm | 800x400 |
| Max. Table Travel | mm | 920x450 |
| T Slots (Width x No.) | mm | 14×3 |
| Distance from Spindle Center to Table Surface | mm | 580 |
| Max. Work Load | kg | 700 |
| Wheel Size (Dia x Width x Bore) | mm | 355x40x127 |
| Spindle Speeds | rpm | 1450 |
| Table Longitudinal Speed (X axis) | m/min | 5~25 |
| Table Horizontal Feed Amount(Y axis) | Continuous | mm/min | 990 |
| Front/Rear Automatic Feed | mm | 0.1-10 |
| Handwheel Rotation Distance | mm | 5 |
| Handwheel Grid | mm | 0.02 |
| Vertical/Wheel Feed | Handwheel Rotation Distance | mm | 0.5 |
| Handwheel Grid | mm | 0.002 |
| Automatic Feed | mm | 0.005-0.025 |
| Rapid Moving Speed | mm/min | 230 |
| Spindle Motor | kW | 5.5 |
| Coolant Pump | W | 180 |
| Hydraulic Motor | kW | 2.2 |
| Parallelism from Machined Surface to Base | mm | 0.008 |
| Surface Roughness | μm | Ra0.63 |
| Machine Weight | kg | 1860 |
| Packing Weight | kg | 2000 |
| Machine Size (LxWxH) | mm | 3050x2200x1960 |
| Packing Size (LxWxH) | mm | 3250x2250x2150 |
