4-5t/H Farm Feed Processing Machine Vertical Tmr Mixer Machine Grass Feed Mixing Machine for Sheep

Product Description

4-5t/h Farm Feed Processing Machine Vertical TMR Mixer Machine Grass Feed Mixing Machine for Sheep
Product Description
The machine is mainly composed of one or two augers. The spiral auger is divided into left and right rotations. During mixing and stirring, the material is simultaneously stirred and stirred at the middle position of the mixer from each direction of both ends of the box. Each spiral lead on the spiral body is equipped with a moving blade, and the fixed teeth on the center line of the feed mixer are used for cutting work. The various fibrous forages and straws passed through are cut and agitated so as to achieve complete mixing of the crushed and mixed Dietary feeding effect.
Product Parameters

Model	9TMRL-5	9TMRL-9	9TMRL-12	9TMRL-16
Motor Power(kw)	15	22	30	22+22
Capacity(T/H)	2-3t/h	4-5t/h	6-7t/h	8-10t/h
QTY of blades(PCS)	5	8	8	16
QTY of twisted dragon(PCS)	1	1	1	1
Bottom plate thickness	14mm	16mm	16mm	18mm
Side plate thickness	5mm	8mm	8mm	8mm
QTY of twisted dragon(PCS)	Nanchang JiangLing	Nanchang JiangLing	Nanchang JiangLing	Nanchang JiangLing
Dimension(mm)	3100*1900*2100mm	3900*2300*2500m	4600*2400*2600m	5800*2500*2600m
Weight(kg)	1900kg	2800kg	3600kg	5000kg

Three Type
1)Electric Motor Type
2)Diesel Engine Type
3)PTO Type

Raw Material
Working Process
Our Advantages
Packaging & Shipping
Our Service And FAQ
Our service
1.We can provide you the one year warranty but without the spare parts.
2.The professional and timely 24 hours after-sale service.
3.The relative video of the machine installation and instruction will be provided for you.
4.We can provide you the different mould to meet your different requirements.
5.We can also meet the special voltage demand.
6.The engineer is available to service machinery oversea
FAQ:

Q1:what are your raw material to mix? ------Grass, alfalfa, stalk, straw, grains powder

Q2:how many cubes do you need for this series mixer ? ------3CBM, 5CBM, 9CBM; 13CBM; 15CBM etc

Q3:What's the certification of your TMR feed mixer? ------CE Certification.

Q4:What's the warranty of TMR feed mixer? ------Warranty:1 Year(except spare parts).

Q5: What's your payment terms? ------Payment terms: T/T; L/C; Western Union; Money Gram.

Customer Feedback
Five-star praise form customer

---
