High Quality PU Nitrile Lining No-Dig Pipe Rehabilitation Liner 100

Product Description

No-Dig Pipe Rehabilitation Liner 100
Product Description
ZYfire Hose Corporation, founded in 2000, we research and produce Lay flat frac hose, fire hose, rack hose, industrial hose, forestry hose, snow-making hose, irrigation hose, drag hose, potable water hose, No-dig pipe rehabilitation liner, TPR layflat hose, hose couplings, landing valves and other fire fighting equipments.
Water solution Liner 100
Raw Materials:
High tenacity fabric reinforcement layer,
Abrasion resistance PE cover,
TPU tube (NSF61 certified, potable water safety approved by NHFPC of China)
Three layers:Inner: Modified TPU layerHigh Tenacity Fabric Reinforcement LayerOuter: Abrasion-resistant PE layer

Description	Parameter
Host Pipes ID:	50mm - 800mm (2" - 32")
Max. Operation Pressure:	1.0 - 4.0 Mpa/145 psi - 580 psi
Max. Bursting Pressure:	3.0 - 12.0 Mpa/435 psi - 1740 psi
Max. Length of Installation:	≥3000m (9900ft)
Wall Thickness:	4mm - 8mm
Abrasion Resistance (DIN 53516)	10.5mm3
Temperature of Media:	Up to 50ºC (122ºF)
Installation Mode:	Fold in U-shape
Pulling Speed:	Up to 400m/h
Service Life Duration:	20years
All above technical parameters depends on diameter.
