Smart Home Multiple Protocol Intelligent Gateway Iot Gateway Products

Product Description

Manufactory and Trading Combo Wifi Gateway FBox-Wifi
FLEXEM is committed to offering you customized integrated solutions, optimal design and most suitable quality products to meet your detailed requirements.
FLEXEM endeavors in saving your developing time, minimizing your operation costs to enable you to focus on your core-competitiveness.
FLEXEM is dedicated to providing you with easy-to-use hardware platform and developing platform. With professional design and friendly interface, FLEXEM is devoted to inspiring your creativity and maximizing your efficiency and productivity.
FLEXEM helps you simplify the complex procedures wholeheartedly.
Combining "Flexible" and "Embedded", FLEXEM(-transliteration of English name) comes to design the flexible embedded operating systems for you.
With head office and researching & developing center (R&D) in Shanghai, factory and logistics center in Shenzhen, FLEXEM Technology (Shanghai ) Co., Ltd. is committed to design the flexible embedded operating systems to optimize your resources by simplifying the operation, minimizing operation and training costs, and maximizing efficiency and productivity.
With independent developed software and hardware platform, FLEXEM provides you with professional software and hardware products and customized solutions. It includes industrial resistive / capacitive multi-touch HMIs, programmable PLC, text displayer, gateway etc. FBox series products are local intelligent data collection terminals of industrial IIoT platform pushed by Flexem, which can realize on-site devices remote data collection, remote downloading and maintenance. It supports over 350 industrial devices drives protocols, various communication connections to most industrial controller devices. It supports variable internet ways and Flexem cloud server, and you can realize remote equipping, diagnose and managing functions.

Hardware	Ethernet	Ethernet, WiFi
	CPU	600MHz ARM Cortex-A8
	Storage	128MB Flash + 128MB DDR3
	Ethernet	3 lines of 10M/100M Ethernet Port
	SD Card Port	Available
	USB Port	1 USB Device 2.0,1 USB Host 2.0
	IO Port	2-line optoelectronic isolated digital input, 2-line relay output (Maximum 5A)
	Serial Communication Ports	COM1: RS232/RS485/RS422 COM2: RS485 COM3: RS232
	WiFi	IEEE 802.11b/g/n compatible WLAN IEEE 802.11e QoS Enhancement (WMM)
	RTC	Built-in
Electrical Specifications	Rated Power	< 5W
	Rated Voltage	DC24V,working range: DC 9V~28V
	Power Protection	Protect from thunder strike and surging
	Power Loss Permit	< 3mS
	CE & RoHS	It is complied with EN61000-6-2:2005,EN61000-6-4:2007, RoHS, Surging:±1KV,Group pulse:±2KV, Electro Static 4KV,Air Discharge: 8KV
Environment Specifications	Working Temperature	-10~60ºC
	Storage Temperature	-20~70ºC
	Environment Humidity	10~90%RH (non condensation)
	Anti-vibration	10~25Hz (X/Y/Z direction 2G/30 minutes)
	Cooling	Natural cooling
Mechanic Parameters	Dimension	130mm*94mm*48mm (without arial)
	Weight	About 400g
	Material	ABS engineering plastics
Software Parameters	VPN Pass-through	Available
	Data Monitoring	300 points, it supports timing uploading or variable uploading.
	Alarming Push	100 points, it supports clients push, SMS push (20 items free everyday), wechat public NO push.
	Historical Data	30 points, it supports offline transfer, each point can store 50000 items when offline, and the data can be kept for 90 days
	Edge Calculation	It supports scripts programming.
	Network Protocols	It supports over 100 industrial devices protocols.
	Managing& Maintenance	It supports firmware upgrading remotely, and equipping files lead in/out

---
