High Efficiency Super Fineness Bead Mill for Nanometer Materials/ Coating/ Paint/ Ink

Product Description

Product Description The delivery pump circulates the materials in the tank and the materials in the grinding chamber. The main shaft in the grinding chamber is equipped with many pins with high anti-abrasiveness and hardness. The pins drive the grinding medium inside the grinding chamber to do irregular movements in all direction to put the materials under the action of constant collision and friction. At same time, the materials are separated from the grinding medium by the sieve and keep circulating from the tank to the grinding chamber to obtain smaller particle size, narrower particle size range.

Features • Novel structure, high stability.

• Strengthened frame with reasonable structure, steady operation and easy maintenance. Besides, nicer appearance with full of modern sense.
• The main parts an out-sourced parts are international renowned brands with higher stability and longer service life.Easy to clean, strong durability.
• Unique tri-pole mechanism design makes it easy to open for cleaning and replacing grinding chambers.
• The grinding chamber, made of high wear-resistance alloy steel, is treated specially to realize higher wear resistance and longer service life. In addition, famous Dual-end Mechanical Seal with self-lubricating system contributes directly to higher reliability and durability.Safe monitor, stable product.
• The machine is with triple cooling: internal, external, and end face, which ensures the grinding heat exchanged out in time.
• The water temperature, material temperature, material pressure,water pressure, air pressure and other real-time monitoring and protection system ensure proper operation of the machine.Full specification, can be customized.
• Specifications ranges from 5L to 50L, which can be customized to be Ex-proof type. Applications Suitable for printing ink, solvent ink, water-based ink, automobile paint, industrial coating, pigments, color paste, and nanometer materials.
Product Parameters

Model	Volume (L)	Dimension (L×W×H) (mm)	Motor (kw)	Feeding Speed (L/min)	Capacity (kg/h)
WMZ-15	15	1210×765×1420	15	0-17	50-500
WMZ-25	25	1370×800×1600	22	0-17	70-700
WMZ-30	30	1580×850×1650	22	0-17	80-800
WMZ-50	50	1920×1050×1700	30	0-40	100-1000
